J. STARTUP AND OPERATION
J.2 Remote Control Operation
1. Power: Turn the air conditioner on and off. This button will clear the TIMER setting.
2. MODE: Press the button to select the mode of operation, AUTO, COOL, DRY, FAN ONLY, HEAT.
Note: The HEAT mode is only for some heating models. If you do not need it, press the MODE button for
more than 5 seconds to delete the HEAT function, and the COOL mode will be selected automatically. Press
the MODE again for more than 5 seconds to add the HEAT function, and the HEAT mode will be selected
automatically.
3. + And - : Use these buttons to increase or decrease the setting Temperature or Timer. Setting
temperature range: 61 ~88°F or 16 ~31°C .
Note: After setting temperature with remote using the + and - buttons, both the remote display
and the unit display will automatically turn off after a short time. This does not affect the unit
operation.
4. TURBO: When the remote is ON, press the button to activate the TURBO function, under
AUTO/COOL/FAN ONLY mode. Press again to cancel the TURBO function, and the fan speed will
change to pre-setting before.
Note: °F and °C change: After inserting the batteries, in the off state within 3 minutes, press
the TURBO button for more than 5 seconds to switch the Fahrenheit (°F) or Celsius (°C) degree
display.
5. DISPLAY: When the unit is ON, press the button, to switch off/on all lights or LED display. And
this function will be canceled when changing mode.
6. TIMER: Use the button to set the TIMER, or cancel the TIMER.
TIMER OFF: When the unit is ON, the timed OFF is programmed by pressing TIMER button, the
remote will display 6 hours pre-setting at first.
Set the rest time by pressing the button or until the needed rest time display, then press TIMER
button again to confirm.
TIMER ON: When the unit is OFF, the timed ON is programmed by pressing TIMER button, the
remote will display 6 hours pre-setting at first. Set the rest time by pressing the button or until
the needed rest time display, then press TIMER button again to confirm. Later, the remote screen
will keep display [TIMER] icon.
Note: When TIMER ON, it cannot select Sleep mode, but can pre-set Mode, temperature, fan
speed, ECO.
7. SLEEP: Press the SLEEP button, all of the display lights will turn off after a while, but the
Sleep light is always on. In SLEEP mode, the air conditioner will automatically adjust the tem-
perature and fan speed to make the room more comfortable during the night. The set tempera-
ture will automatically raise every 30-60 minutes and at most change six times until the set
temperature is 81 or 82°F. This function can be selected when COOL or HEAT mode.
8. FAN SPEED: Press the FAN SPEED button to choose the fan speed options. You can choose Hi,
Med, Lo or Auto speed in COOL or HEAT mode and choose Hi, Med, Lo in FAN mode. When DRY
mode, it is only Low fan speed.
9. MONEY SAVER: When the unit is in COOL mode, press the button to MONEY SAVER function.
In MONEY SAVER mode, the unit will turn off once the room is cooled to the user set tempera-
ture. The unit will turn back on when the room temperature rises above the user set tempera-
ture. Before the compressor starts, the fan motor will run for 20 sec., then it will stop for 10
min., and will repeat to provide a much more comfortable feeling and save energy.
10. Child Lock: Press the + or - button for more than 2 seconds to lock or unlock the remote
controller. When locked, each function button is noTuseful, and the lock icon will flash when any
button is pressed.
Battery size: AAA
Note: Do not mix old and new batteries or different types of AAA batteries.
1
2
33
4
5
67
8
9
1. Power: Turn the air conditioner on and off. This button will
clear the TIMER setting.
2. Press the button to select the mode of operation, AUTO, COOL,MODE:
DRY, FAN ONLY, HEAT.
The HEAT mode is only for some heating models. If you do notNote:
need it, press the MODE button for more than 5 seconds to delete the
HEAT function, and the COOL mode will be selected automatically.
Press the MODE again for more than 5 seconds to add the HEAT
function, and the HEAT mode will be selected automatically.
3. And : Use these buttons to increase or decrease the setting
Temperature or Timer. Setting temperature range: 61 ~88 or 16 ~31 .Ё
When the remote controller is turn-of
f, press and buttons canNote:
pre-set the temperature. After the setting, the remote temperature display
will be off after a while.
4. When the remote is ON, press the button to active the TURBOTURBO:
function, under AUTO/COOL/FAN ONLY mode. Press again to cancel the
TURBO function, and the fan speed will change to pre-setting before.
and change: After insert the batteries, in the off state within 3Note: Ё
minutes, press the TURBO button for more than 5 seconds to switch the
Fahrenheit ( ) or Celsius ( ) degree display.Ё
5. When the unit is ON, press the button, to switch off/on all lightsDISPLAY:
or LED display. And this function will be canceled when changing mode.
6. Use the button to set the TIMER, or cancel the TIMER.TIMER:
When the unit is ON, the timed OFF is programmed byTIMER OFF:
pressing TIMER button, the remote will display 6 hours pre-setting at first.
Set the rest time by pressing the button or until the needed rest time
display, then press TIMER button again to confirm.
When the unit is OFF, the timed ON is programmed by pressingTIMER ON:
TIMER button, the remote will display 6 hours pre-setting at first. Set the
rest time by pressing the button or until the needed rest time display,
then press TIMER button again to confirm. Later, the remote screen will keep
display [ ] icon.TIMER
When TIMER ON, it cannot select Sleep mode, but can pre-set Mode,Note:
temperature, fan speed, ECO.
7. Press the SLEEP button, all of the display lights will turn off after aSLEEP:
while, but the Sleep light is always on. In SLEEP mode, the air conditioner
will automatically adjust the temperature and fan speed to make the room
more comfortable during the night. The set temperature will automatically
raise every 30-60 minutes and at most change six times until the set
temperature is 81 or 82 . This function can be selected when COOL orЁ
HEAT mode.
8. Press the FAN SPEED button to choose the fan speed options.FAN SPEED:
You can choose Hi, Med, Lo or Auto speed in COOL or HEAT mode and
choose Hi, Med, Lo in FAN mode. When DRY mode, it is only Low fan speed.
9. When the unit is in COOL mode, press the button toMONEY SAVER:
MONEY SAVER function. In MONEY SAVER mode, the unit will turn off
once the room is cooled to the user set temperature. The unit will turn back
on when the room temperature rises above the user set temperature. Before
the compressor starts, the fan motor will run for 20 sec., then it will stop for
10 min., and will repeat to provide a much more comfortable feeling and
save energy.
10.
pressing the button or for more than 2 seconds to lockChild Lock:
or unlock the remote controller
. When locked, each function button is no
useful, and the lock icon will flash when press any button.
+
-
+
-
+
-
+
-
+
-
