8
A. IMPORTANT SAFETY AND GENERAL INFORMATION
A.5 Product Inspection / Packing List
Upon receiving the unit, inspect it for any damage from shipment. Claims for damage, either shipping or concealed, should be filed
immediately with the shipping company. IMPORTANT: Check the unit model number, Cooling size, electrical characteristics, and
accessories to determine if they are correct.
Figure A.4 (Packing List)
IMAGE PART QUANTITY
Through-The-Wall Air Conditioner 1
Remote Control 1
Trim Frame 1 (Left & Right legs) 2
Trim Frame 2 (Top & Bottom legs) 2
Back Steel Grille 1
Rear plastic net 1
1/2" Long Hex-head Screw 4
Grounding wire with tooth washer 1
DIMENSION (W x H x L) PART QUANTITY
1" x ¾" x 13¾" Seal Sponge 2
1" x ¼" x 13¾" Seal Sponge 2
1" x ¼" x 25" Seal Sponge 3
1" x 1½" x 25" Seal Sponge 3
1" x 1½" x 13¾" Seal Sponge 2
1" x 1½" x 84" 1
Seal Cotton3⅜" x 1½" x 4½" 4
¾" x 1½" x 16¾" Seal Cotton 2
Seal Sponge
To Next Page
