Friedrich UNI-FIT US08B10A User Manual

—19—
4. SCHEMATIC DIAGRAM
4.1 CIRCUIT DIAGRAM
• MODEL : US08B10A-A, US10B10A-A, US12B10A-A, US10B30A-A, US12B30A-A
264110 POWER CORD 67300012 67300012 67300013 67300015 67300015 1
346811 FAN MOTOR 67303021 67303022 67303023 67303024 67303025 1
W0CZZ CAPACITOR 67300710 67300717 67300717 67300708 67300708 1
567502 OVERLOAD PROTECTOR 67301406 67301409 67301407 67301413 67500056 1
LOCATION
NO.
Q'TY
PER SET
REMARKS DESCRIPTION
US08B10A-A US10B10A-A US12B10A-A US10B30A-A US12B30A-A
PART NO.

Friedrich UNI-FIT US08B10A Specifications

General

Brand	Friedrich
Model	UNI-FIT US08B10A
Category	Air Conditioner
Language	English
