5
920-075-09
Note: All eld wiring must comply with NEC and local codes. It is the responsibility of the installer to insure that the electrical codes are met.
Electrical Requirements
Wire Size Use O NLY wiring size recommended for single outlet branch circuit.
Fuse/Circuit Breaker
Use ON LY type and size fuse or HACR circuit breaker indicated on unit's rating plate (See sample on next page). Proper current
protection to the unit is the responsibility of the owner.
Grounding
Unit MUST be grounded from branch circuit to unit, or through separate ground wire provided on permanently connected units.
Be sure that branch circuit or general purpose outlet is grounded.
Wire Sizing
Use recommended wire size given in tables and install a single branch circuit. All wiring must comply with local and national
codes. NOTE: Use copper conductors only.
CAUTION
Electric shock hazard.
Turn OFF electric power before service or installation.
All electrical connections and wiring MUST be installed by a qualied electrician and
conform to the National Electrical Code and all local codes which have jurisdiction.
Failure to do so can result in property damage, personal injury and/or death.
All 208/230v chassis must be hard wired with properly sized breaker. See nameplate for specic chassis electri-
cal requirements. See gure 8 for unit wiring and wall thermostat wiring. See page 7 for wire size. Use HACR
type breakers to avoid nuisance trips. All eld wiring must be done in accordance with NEC and local codes.
Sample Nameplate
MODEL NO 1
SERIAL NO *
FRIEDRICH AIR CONDITIONING CO.
SAN ANTONIO, TEXAS
VOLTS: 24,33,34
VOLTAGE RANGE: 255-197
REFRIG CHARGE: 7 OZS. R22
DESIGN PRESSURE: 575 PSIG HS / 150 PSIG LS
COOLING: BTU/HR 8
SEER: 10 COP: 16
HEAT PUMP BTU/HR: 14
TOTAL COOLING AMPS: 9
TOTAL ELEC. HEAT AMPS: 15
ELECTRIC HEAT WATTS: 18
FOR PERMANENTLY CONNECTED UNITS ONLY:
COMP'. PLA 11 LRA 12
MOTOR: FLA 13 HP 19
HEATER AMPS: 17
MIN. CKT AMP ~0 USE ~1 MAX. TIME DELAY FUSE
OR HACR TYPE CIRCUIT BREAKER.
GENERAL UNIT INFORMATION:
MAX OUTLET AIR TEMPERATURE: 2OO'F
MAX EXTERNAL STATIC PRESSURE ELECTRIC
HEAT'..5 IN. WATER
"O" CLEARANCE TO COMBUSTIBLE MATERIAL
USE ON SINGLE OUTLET CIRCUIT ONLY
ELECTRICAL SHOCK AND
MOVING PARTS HAZARD
CAN CAUSE INJURY OR
DE ATH
PULL OUT DISCONNECT
HEAD LOCATED ON THE
FRONT OF THIS UNIT TO
DISABLE POWER BEFORE
SERVICING.
LISTED
120524
HEATING AND
COOLING EQUIPMENT
APPLICABLE PATENTS: US
6,065,296
NY MEA NO.: 295-00-E
USE ONE OF THE
FOLLOWING ITEMS
FROM EACH CATEGORY
TO COMPLETE THE
A S SE M B LY
WALL PLENUM:
VPAWP1 -8
VPAWP1 -14
OUTDOOR GRILLE
VPAL 2
INDOOR GRILLE
VPRG1
VPRG2
VPRG5
SAMPLE
WARNING
Electrical Rating Tables
NOTE: Use copper conductors ONLY. Wire sizes are per NEC. Check local codes for overseas applications
Recommended branch circuit wire sizes*
Nameplate maximum circuit breaker size AWG Wire size**
15A 14
20A 12
30A 10
AWG — American Wire Gauge * Single
circuit from main box. ** Based on copper
wire, single insulated conductor at 60°C
