VPAK 9-18K BTU UNITS
COMPONENTS IDENTIFICATION
14
Air Intake
Ground
Front Side
Blower Wheel and
Heater in here
10” Duct Collar
Right Side
Left and Front Sides
Left and Back Sides
Condenser
Heater
Diagnostic
Touch Pad
Fresh Air
Vent
Evaporator
Coil
Condenser
Coil Thermistor
Evaporator
Coil Thermistor
Compressor
Evaporator Coil
Pullout
Disconnect
Compressor
Blower/Fan
Motor Capacitor
Heater
Blower
Wheel
Condenser
Air Intake
Blower/Fan
Motor
Condenser
Fan Shroud
Fresh Air
Vent Door
Nameplate
Air Discharge
Condenser
Condenser
Air Discharge
