Friedrich WallMaster 2009 - Performance Data and Dimensions

6
2008 / 2009 PERFORMANCE DATA
* Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp & 40% relative humidity
Model Height Width Depth
Depth
with
Front
Minimum
Extension
Into Room
Minimum
Extension
Outside
Thru-the-wall
Finished Hole
Height Width
WSC Sleeve
Chassis
16 3/4" 27" 16 3/4" 23" 7 1/2" 9/16" 17 1/4" 27 1/4"
15 3/4" 26 1/2" 21" – – – – –
Sleeve / Chassis Dimensions
COOLING
PERFORMANCE
DATA*
EVAPORATOR AIR
TEMP. DEG. F
EVAPORATOR TEMP.
DEG. F
CONDENSER
TEMPERATURE
DEG. F
Discharge
Temp
Suction
Temp
Liquid
Temp
Super Heat
Sub-
Cooling
OPERATING
PRESSURES
ELECTRICAL RATINGS R-22 REF.
Evap
CFM
Motor
RPM
BREAKER
FUSE
Discharge
Air
Temp.
Drop F.
T(in) T(out) Suction Discharge Amps Cool Amps Heat
Locked Rotor
Amps
Charge in
OZ.
60 Hertz
Amps
WS08B10A-D 55 25 55 55 127 165 61 102 18 25 87 281 7.1 36.2 20.5 257 1100 15
WS08B10A-F 55 25 55 55 125 179 74.5 102 18 25 87 281 6.9 36.2 18.9 257 1100 15
WS10B10A-D 52 28 53 51 128 176 68 105 16 24 79 293 9.0 45.0 22.0 248 1100 15
WS14B10A-D 52 28 52 52 128 179 63 99 14 28 82 297 12.4 58.0 44.9 293 1300 15
WS14B10A-E 52 28 52 52 128 179 63 99 14 28 82 297 12.4 58.0 44.9 293 1300 15
WS10B30A-D 55 25 53 57 131 179 68 106 16 23 77 289 4.6 26.0 22.5 235 1100 15
WS13B30B-E 50 30 52 50 131 180 61 103 13 24 81 305 6.9/6.5 27.4 36.5 288 1280 15
WS13B30B-F 50 30 52 50 131 180 61 103 13 24 81 305 6.9/6.5 27.4 36.5 288 1280 15
WS16B30A-D 52 28 51 53 121 154 54 99 18 32 74 315 7.7 35.0 47.6 292 1421 15
WS16B30A-E 52 28 51 53 121 154 54 99 18 32 74 315 7.7 35.0 47.6 292 1421 15
WE10B33A-C 53 27 54 52 126 180 82 99 16 31 82 289 4.6 15.2 45.0 38.0 225 1074 20
WE10B33C-A 53 27 54 52 126 180 82 99 16 31 82 289 4.6 15.2 45.0 38.0 225 1074 20
WE13B33B-D 50 30 52 50 131 180 61 103 13 24 81 305 6.9/6.5 15.7 27.4 36.5 288 1280 20
WE13B33C-A 50 30 52 50 131 180 61 103 13 24 81 305 6.9/6.5 15.7 27.4 36.5 288 1280 20
WE13B33B-E 50 30 52 50 131 180 61 103 13 24 81 305 6.9/6.5 15.7 27.4 36.5 288 1280 20
WE16B33A-C 52 28 51 53 121 174 57 100 18 30 74 315 6.5 16.1 35.0 35.2 281 1305 20
WE16B33C-A 52 28 51 53 121 174 57 100 18 30 74 315 6.5 16.1 35.0 35.2 281 1305 20
WE16B33A-D 52 28 51 53 121 174 57 100 18 30 74 315 6.5 16.1 35.0 35.2 281 1305 20
WY10B33A-C 53 27 54 52
126 180 66 99 16 31 82 225 4.6 4 / 15.2 26.0 38.0 225 1074 20
WY10B33C-A 53 27 54 52 126 180 66 99 16 31 82 225 4.6 4 / 15.2 26.0 38.0 225 1074 20
WY10B33A-D 53 27 54 52 126 180 66 99 16 31 82 225 4.6 4 / 15.2 26.0 38.0 225 1074 20
WY13B33A-C 52 29 52 51 127 180 64 103 16 29 80 300 6.5 5.6 / 15.7 27.4 35.0 260 1200 20
WY13B33C-A 52 29 52 51 127 180 64 103 16 29 80 300 6.5 5.6 / 15.7 27.4 35.0 260 1200 20
WY13B33A-D 52 29 52 51 127 180 64 103 16 29 80 300 6.5 5.6 / 15.7 27.4 35.0 260 1200 20
ENERGY STAR
®
modelsSpecifications
Model
Cooling
Capacity
BTU/h
Heating
Capacity
BTU/h
Volts
Rated
Cooling
Amps
Cooling
Watts
Heating
Amps
Heating
Watts
Energy
Eciency
Ratio
EER
Moisture
Removal
Pints/Hr.
Room
Side Air
Circulation Sleeve
Weight
Lbs.
Ship/Net
WALLMASTER
WS08B10A 8000 — 115 6.8 762 — — 10.5 1.3 245 WSC 97/93
WS10B10A 10000 — 115 8.7 954 — — 10.5 2.4 245 WSC 107/103
WS14B10A 13500 — 115 12.0 1415 — — 9.5 3.3 295 WSC 116/112
WS10B30A 10000/10000 — 230/208 4.6/5.0 1005/996 — — 10.0/10.0 2.1 260 WSC 105/101
WS13B30B 12500/12000 — 230/208 6.3/6.7 1404/1379 — — 8.9/8.7 3.3 280 WSC 113/109
WS16B30A 15800/15000 — 230/208 7.8/8.5 1756/1705 — — 9.0/8.8 4.2 290 WSC 123/119
WE10B33C 10000/10000 11000/9100 230/208 4.6/5.0 1005/996 16.0/14.7 3550/2950 10.0/10.0 2.1 260 WSC 107/103
WE13B
33C 12500/12000 11000/9100 230/208 6.3/6.7 1404/1379 16.0/14.7 3550/2950 8.9/8.7 3.3 280 WSC 115/111
WE16B33C 15800/15000 11000/9100 230/208 7.8/8.5 1756/1705 16.0/14.7 3550/2950 9.0/8.8 4.2 290 WSC 125/121
WY10B33C 10100/9800 8100/7800 230/208 4.6/4.8 1013/976 3.9/4.0 857/821 10.0/10.0 2.5 230 WSC 111/107
WY13B33C 12500/12100 10400/10000 230/208 6.4/6.8 1389/1352 5.4/5.7 1182/1136 9.0/9.0 3.2 280 WSC 120/116
