82 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
35 61896042 EVAPORATOR COIL ASSY
USED ON WCT08A10-D AND
LATER
WCT08A10A-D 1
35 62103319 EVAPORATOR COIL ASSY
WES.312X4X16RC2E45A23X11H6
WET16A33A, WCT16A30A 1
35 62103318 EVAPORATOR COIL ASSY
WES.375X3X16RC2V45A23X11H6
WCT10A10A, WCT10A30A 1
40 61850266 CONDENSOR COIL ASSY
WCS.250X5X16XC9K45A17X15H3
WET16A33A, WCT16A30A 1
40 61850207 CONDENSOR COIL ASSY
WCS5MMX5X18XC9X39A17H0
WET12A33A, WET16A33A, WCT12A10A-A, WCT12A10A-C
WCT12A30A, WCT16A30A-D, WET16A33A-D, WCT12A10B,
WCT12A30B
1
40 61896312 CONDENSOR COIL ASSY WCT12A10A-D, WCT12A30A-D, WET12A33A-D 1
40 61850208 CONDENSOR COIL ASSY
WCS5MMX3X16RC9X39A17H2
WET10A33A, WCT08A10A, WCT10A10A, WCT10A30A 1
40 61896041 CONDENSOR COIL ASSY WCT08A10A-A, WCT0810A-B, WCT08A10A-C 1
40 61896318 CONDENSOR COIL ASSY WCT08A10A-D 1
40 61896215 CONDENSOR COIL ASSY
WCS.312X4X16RC2V45A17X15H6
WHT12A33A 1
45 62101901 DRAINPAN ASSY ALL 1
50 62106200 DRAINPAN HEAT SHIELD ALL 1
55 61883102 PAD ISOLATION 3X6 ALL 1
60 67000210 CHECK VALVE AND CAP TUBE
ASSY KIT
(INCLUDES CHECK VALVE AND
CAP TUBE ASSY (PN 6216807),
2 STRAINERS, AND 2 STRAINER
HOLDERS
WHT12A33A 1
60 67000211 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN 62104624), STRAINER, AND
STRAINER HOLDER
WET16A33A, WCT16A30A 1
60 67000212 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN 62104445), STRAINER, AND
STRAINER HOLDER
WET12A33A, WCT12A30A 1
60 67000213 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN 62104449), STRAINER, AND
STRAINER HOLDER
WET10A33A, WCT10A30A 1
60 67000214 CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN 62104435), STRAINER, AND
STRAINER HOLDER
WCT12A10A-A, WCT12A10A-C 1
60 TBD CAP TUBE ASSY KIT
(INCLUDES CAP TUBE ASSY
(PN 62104480), STRAINER, AND
STRAINER HOLDER
WCT12A10A-D 1
PARTS CATALOG
FIGURE 902
