Frigidaire 134897500B - Rough-Ln Dimensions

6
25 ¼ IN.
(64.13 CM)
4 13/16 IN. (12.22 CM)
2 ½ IN.
(6.35 CM)
47“
16 ¼ IN.
(41.27 CM)
36 1/16IN.
(91.60 CM)
30 13/16 IN.
(78.26 CM)
11 7/16 IN. (29.5 CM)
1 7/8 IN.
(4.76 CM)
3 ¾ IN.
(9.52 CM)
9 3/8 IN.
(23.81 CM)
41 ¼ IN
(104.77 CM)
29 7/16 IN
(74.77 CM)
27 IN.
(68.58CM)
DRAIN OUTLET
(REAR)
WATER INLETS
(REAR)
VENT
5 ¼ IN.
(13.33 CM)
GAS SUPPLY
PIPE (REAR)
43 IN.
(109.22 CM)
54 5/16 IN.
(137.95 CM)
75 ½ IN.
(191.77 CM)
43 IN.
(109.22 CM)
ELECTRICAL CONNECTION
12 ½ IN.
(31.75 CM)
ROUGH-IN DIMENSIONS
