8
UNPACKING WASHER
Í
NOTE
Rubber expansion material on spacers may need
time to relax before they can be easily pulled through
shipping hole.
IMPORTANT
Save all shipping bolts and spacers for future use. If
the washer is to be transported at a later date, the
shipping hardware must be reinstalled to help prevent
shipping damage.
x 4
4 HOLE PLUGS
(IN BAG)
Locate 4 hole plugs in the small bag supplied
with washer instruction guides. Insert them in
the holes in washer back panel.
Removing shipping hardware
Installing hole plugs
Remove all of the following:
4 SPACERS
4 BOLTS
2 P CLAMPS
x 4
x 2
x 4
4 SPACERS
4 BOLTS
2 P CLAMPS
To Next Page
