Frigidaire Affinity 6000 Series User Manual (English)

Questions and Answers:

W
wbraunAug 21, 2025
What to do if my Frigidaire Washer does not start?
- L
  Lorraine JohnsonAug 21, 2025
  If your Frigidaire washer doesn't start, ensure the power cord is securely plugged into the wall outlet. Check your house fuse or circuit breaker and reset it if necessary, but do not increase the fuse capacity. Make sure your water supply faucets are turned on. If the motor has overheated, it will automatically restart after a cool-down period of up to 30 minutes, unless you manually turned the washer off. Also, verify that the dispenser drawer is completely closed. These issues can be caused by a loose power cord, a blown fuse or tripped circuit breaker, closed water supply faucets, an overheated motor, or an open dispenser drawer.
T
Tara GrayAug 23, 2025
Why Frigidaire Affinity 6000 won’t spin?
- J
  Julia SantiagoAug 23, 2025
  If your Frigidaire washer isn't spinning, make sure the door and dispenser drawer are completely closed. If the load is too small, add one or two similar items to help balance it. The causes of this issue can be an unclosed door, an unclosed dispenser drawer, or a load that is too small.
D
Deborah ThomasAug 25, 2025
Why Frigidaire Affinity 6000 is not filling with water?
- T
  Thomas RomeroAug 25, 2025
  If your Frigidaire washer isn't filling with water or is filling slowly, first, check another faucet in your house to ensure the water supply is adequate. Wait until the water supply and pressure increase. Fully open both the hot and cold water faucets. Ensure water pressure is at least 30 psi (260 kPa), and avoid running water elsewhere in the house while the washer is filling. Straighten any kinks in the water inlet hoses and clean the inlet screens. The causes could be an inadequate water supply, water supply faucets not fully open, water being used elsewhere in the house, kinked water inlet hoses, or plugged water inlet screens.
T
tanner70Aug 27, 2025
What to do if Frigidaire Affinity 6000 water does not drain?
- T
  Thomas MartinezAug 27, 2025
  If water in your Frigidaire washer does not drain or drains slowly, clean and straighten the drain hose. The maximum standpipe height is 8’ (2.4 m). This issue is caused by a kinked or clogged drain hose.
N
natalie76Aug 27, 2025
How to fix water leaks in Frigidaire Affinity 6000?
- S
  Steven NewmanAug 28, 2025
  If you're experiencing water leaks with your Frigidaire washer, check and tighten the fill hose connections at the faucet or washer. Install the rubber sealing washers provided. If the house drain pipes are clogged, unclog them, or contact a plumber if necessary. This can be caused by a loose fill hose connection or clogged house drain pipes.
E
Elizabeth JohnsonAug 29, 2025
How to prevent residue on clothes from Frigidaire Affinity 6000?
- J
  juanscottAug 29, 2025
  If your Frigidaire washer leaves residue or powder on dark items, or makes fabrics feel stiff, try increasing the water temperature to the hottest setting safe for the fabric. Avoid overloading the washer. Consider switching to a liquid detergent or using a non-precipitating water conditioner with your non-phosphate granular detergent. This can be caused by undissolved detergent, the combination of non-phosphate granular detergents with hard water minerals, or overloading the washer.
S
Samuel ScottAug 31, 2025
How to avoid wrinkling with Frigidaire Washer?
- J
  Julie MasonAug 31, 2025
  If your Frigidaire washer leaves your clothes excessively wrinkled, reduce the load size. Rinse clothes in cold water with liquid fabric softener using the Perm Press or Delicate cycle. Remove items from the washer as soon as the cycle is completed. Wrinkling can be caused by overloading the washer or selecting the incorrect wash cycle for the load.
D
David GravesSep 1, 2025
How to fix rattling noise in Frigidaire Affinity 6000 Washer?
- C
  Chris TaylorSep 1, 2025
  If your Frigidaire washer is making a rattling and clanking noise, stop the washer and check the drum for foreign objects like coins or safety pins. If the noise continues after restarting, objects may be in the pump. To prevent unnecessary noise and damage to the drum, fasten fasteners and turn items inside out before washing. This can be caused by foreign objects in the drum or pump, or metal fasteners hitting the wash drum.
M
martinrebeccaSep 3, 2025
How to remove yellow buildup from Frigidaire Affinity 6000?
- J
  julie14Sep 3, 2025
  If you notice a yellow buildup of body soil on synthetic fabrics after washing with your Frigidaire washer, soak the fabrics in a detergent booster or a product containing enzymes. Wash in hot water (120°F/49°C) using the full permanent press cycle. Increase the amount of detergent used, and consider adding bleach or treating the fabrics with a color remover. This issue can arise from agitation time being too short, wash water temperature being too low, or not using enough detergent.
C
Christina MorrisonSep 4, 2025
Why Frigidaire Washer is making a thumping sound?
- C
  Chad AlvaradoSep 5, 2025
  If your Frigidaire washer is making a thumping sound, it is usually normal if you have heavy wash loads. However, if the sound persists, stop the washer and redistribute the wash load. This can be caused by heavy wash loads or the washer being out of balance.

Frigidaire Affinity 6000 Series Specifications

General

Type	Front Load
Capacity	4.5 cu. ft.
Steam Function	Yes
Sanitize Cycle	Yes
Spin Speed	1300 RPM
Energy Star Certified	Yes
Steam Option	Yes
Color	White
Delay Wash	Yes

Summary

Section 1 Basic Information

Safe Servicing Practices

Guidelines to prevent injury and damage during appliance repair.

Serial Number and Model Breakdown

Details on identifying the washer via serial and model number configurations.

Control System Components

Overview of control, drum light, door switch, and door lock assembly functions.

Water Inlet Valve Systems

Details on the electronic water level sensor and water inlet valve assembly.

Major Appliance Warranty Information

Details on the limited warranty coverage, exclusions, and service procedures.

Section 2 Installation Information

Installation Requirements and Tools

Tools needed and pre-installation requirements for washer setup.

Electrical and Grounding Requirements

Specifications for electrical circuits, power supply, and proper grounding.

Unit Dimensions and Clearances

Physical dimensions of the washer and minimum installation clearance requirements.

Water and Drain System Requirements

Specifications for water supply, drain system, and unpacking procedures.

Leveling and Water Connections

Instructions for leveling the washer and connecting inlet water hoses.

Pedestal Installation Guide

Steps for installing the washer onto a 15" drawer pedestal accessory.

Section 3 Electronic Control

Affinity Series Control Panel Layout

Visual guide to the control panel buttons, knobs, and indicators for Affinity washers.

Operating Steps and Cycle Selection

Step-by-step guide for operating the washer and selecting wash cycles.

Cycle Settings and Temperatures

How to adjust wash/rinse temperatures, spin speed, and soil level settings.

Error Codes, Diagnostics, and Testing

How to read error codes, perform diagnostic tests, and clear stored codes.

Failure Code Chart

Comprehensive table listing failure codes, fault conditions, and corresponding checks.

Component Testing Procedures

Detailed tests for common electronic components and their circuits.

Section 4 Component Teardown

Component Teardown Warnings and Cautions

Important safety warnings and cautions before performing component removal procedures.

Door Strike and Loading Door Removal

Procedures for removing the door strike and the loading door assembly.

Detergent Drawer Removal and Disassembly

Instructions for removing and disassembling the detergent drawer and its components.

Electronic Control Board Removal

Guide to safely removing the electronic control board from the console.

Tub Assembly Removal

Comprehensive guide to removing the entire tub assembly, including critical sub-steps.

Section 5 Troubleshooting

Common Washing Problems: Stains, Lint, and Fabric Damage

Troubleshooting guide for common issues like blue stains, lint, and fabric damage.

Troubleshooting: Noise, Vibration, and Start Issues

Diagnosing and resolving noises, vibrations, and the washer not starting.

Troubleshooting: Spin, Drain, Temperature, and Water Issues

Addressing problems with spinning, draining, water temperature, and filling.

Section 6 Wiring Diagrams

Affinity 7000 Series Wiring Diagram

Schematic showing electrical connections for the Affinity 7000 series washer.

Affinity 6000 Series Wiring Diagram

Schematic showing electrical connections for the Affinity 6000 series washer.
