Section 2 Installation Information
2-7
Connecting Drain and Electrical
1. Snap one end of the drain hose hanger (shipped
in washer drum) onto the drain hose. Continue
wrapping it around the hanger and snap it in place.
2. Place the hook end of the drain hose in the drain
opening. Secure the drain hose with the cable tie
(provided in the enclosure package) to the stand-
pipe, inlet hose, laundry tub, etc. so the hose does
not pull out from the force of the water.
3. Plug the power cord into a grounded outlet.
4. Turn on the power at a circuit breaker/fuse box.
5. Carefully slide the washer to its final position.
Recheck for level and rock corners for stability.
Remove and discard door tape.
A wiring diagram and technical data sheet are located
under the washer top panel, on top of the detergent
dispenser housing.
NOTE
Figure 2-9. Drain Hose Installation
Doors
Handles are secure and tight
Door seals completely to cabinet on all sides
Leveling
Washer is level, side-to-side and front-to-back
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Washer plugged in
Water Connections
House water supply turned on
Check for leaks at all connection points
Registration card sent in
Final Checks
Shipping material removed
Run washer through a cycle check for proper operation
Installation Checklist
