Frigidaire ELECTRONIC CONTROL AIR CONDITIONER - Air Conditioner Features

5
DISPLAYS
TEMPERATURE/TIME
FAN SPEED
ADJUSTS
TEMPERATURE
OR TIME
ACTIVATES
TIMER
CHECK FILTER
RESET BUTTON
SETS MODE
TURNS UNIT
ON OR OFF
AUTO TEMP FEATURE
SLEEP MODE
SETS FAN SPEEDS
Auto
Temp
LIGHT
ON/OFF
REMOTE CONTROL
ACTIVATE
S
TIMER
FAN
SPEEDS
SETS
MODES
ADJUSTS
TEMP &
TIMES
Air Conditioner Features
UNIT CONTROL
ELECTRONIC CONTROL OPERATING INSTRUCTIONS
Before you begin, thoroughly familiarize yourself with the control panel and remote as shown below and
all its functions, then follow the symbol for the functions you desire. The unit can be controlled by the
unit control alone or with the remote.
Battery Size: AA
Warning: do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc),
or rechargeable (nickel-cadmium) batteries.
TO TURN UNIT ON: YOU WILL SEE:
NOTE: The following instructions represent the Unit Controls, the same instructions can be used for the Remote Control.
DO THIS:
PRESS ON/
OFF
BUTTON
SZ000728(En)-Yaokong 09/20/2005, 5:30 PM5
