FRIGIDAIRE MODEL SPECIFICATIONS
Model
FAH124S1T-A
FAH124S1T-B
FAH127S2T-A
FAH127S2T-B
Chassis type
TTW3
TTW3
TTW3
TTW3
Capacity features
BTU - Cooling
BTU - Heating
Moisture Removal
EER
12,000
-
1.43
9.4
12,000
-
1.43
9.4
12,000/11,700
-
1.43
9.4
12,000/11,700
-
1.43
9.4
Electrical Information
Voltage
Amps - Cooling
Amps - Heating
Watts - Cooling
Watts - Heating
Fuse/Breaker (Amps)
Receptacle Type
Power Cord Number
Wiring Diagram
Page #
115
11.5
-
1275
-
15A
NEMA6-15
202402260125
202021890125
Page 48
115
11.5
-
1275
-
15A
NEMA6-15
202402260125
202021890125
Page 48
230/208
6.2/6.7
-
1275/1240
-
15A
NEMA6-15
202402260127
202021890125
Page 48
230/208
6.2/6.7
-
1275/1240
-
15A
NEMA6-15
202402260127
202021890125
Page 48
Air Flow System
Capacitor-µ farads
Fan Motor Mfg.
Fan Motor Number
RPM/CMP (EVAP)
High
Medium
Low
Heat Only
15uF 450V
WL
202400420636
-
1400
1290
1180
15uF 450V
BO
202400420636
-
1400
1290
1180
-
4uF 450V
WL
202400420635
-
1400
1290
1180
4uF 450V
BO
202400420635
-
1400
1290
118
0
Refrigeration System
Compressor Mfg.
Compressor Number
Compressor Type
Overload Protector
Capacitor-µ farads
Refrigerant Charge
Restrictor Tube
Thermostat Type
LG
QK156CBA
Rotary
MRA12061-12026
60uF 250V
22.22
201621790447
Electronic
LG
QK156CBA
Rotary
MRA12061-12026
60uF 250V
22.22
201621790447
Electronic
TOSHIBA
PH160X1C-3DZDU
Rotary
B185-135-141C
35uF 440V
23.97
201621790447
Electronic
TOSHIBA
PH160X1C-3DZDU
Rotary
B185-135-141C
35uF 440V
23.97
201621790447
Electronic
Installation Instructions
Kit Type
Part Number
202821890002
202821890002
202821890002
202821890002
Control Thermostat Location
Diagram
Page 55 Page 55 Page 55 Page 55
Condenser Fan and
Evaporator Blower Location
Diagram
Page 64-65 Page 64-65 Page 64-65 Page 64-65
