FRIGIDAIRE MODEL SPECIFICATIONS
Model
FAH146S2T-A
FAH146S2T-B
FAH14ES2T-A
FAH14ES2T-B
Chassis type
TTW3
TTW3
TTW3
TTW3
Capacity features
BTU - Cooling
BTU - Heating
Moisture Removal
EER
14,000/13,600
-
1.86
9.0
14,000/13,600
-
1.86
9.0
14,000/13,600
10,600/8,600
1.86
9.0
14,000/13,600
10,600/8,600
1.86
9.0
Electrical Information
Voltage
Amps - Cooling
Amps - Heating
Watts - Cooling
Watts - Heating
Fuse/Breaker (Amps)
Receptacle Type
Power Cord Number
Wiring Diagram
Page #
230/208
7.3/8.6
-
1550/1520
-
15A
NEMA6-15
202402260127
202021890125
Page 48
230/208
7.3/8.6
-
1550/1520
-
15A
NEMA6-15
202402260127
202021890125
Page 48
230/208
7.3/8.6
15/13.5
1550/1520
3450/2800
20A
NEMA6-20
202402260128
202021890126
Page 49
230/208
7.3/8.6
15/13.5
1550/1520
3450/2800
20A
NEMA6-20
202402260128
202021890126
Page 49
Air Flow System
Capacitor-µ farads
Fan Motor Mfg.
Fan Motor Number
RPM/CMP (EVAP)
High
Medium
Low
Heat Only
5uF 450V
WL
202400400556
-
1550
1450
1350
-
5uF 450V
BO
202400400556
-
1550
1450
1350
-
5uF 450V
WL
202400400556
-
1550
1450
1350
-
5uF 450V
BO
202400400556
-
1550
1450
1350
-
Refrigeration System
Compressor Mfg.
Compressor Number
Compressor Type
Overload Protector
Capacitor-µ farads
Refrigerant Charge
Restrictor Tube
Thermostat Type
Hitachi, Shanghai
SL193SN-C7LU
Rotary
-
40uF 450V
25.75
201621890171
Electronic
Hitachi, Shanghai
SL193SN-C7LU
Rotary
-
40uF 450 V
25.75
201621890171
Electronic
Hitachi, Shanghai
SL193SN-C7LU
Rotary
-
40uF 450 V
25.75
201621890171
Electronic
Hitachi, Shanghai
SL193SN-C7LU
Rotary
-
40uF 450 V
25.75
201621890171
Electronic
Installation Instructions
Kit Type
Part Number
202821890002
202821890002
202821890002
202821890002
Control Thermostat Location
Diagram
Page 55 Page 55
Page 55
Page 55
Condenser Fan and
Evaporator Blower Location
Diagram
Page 64-65 Page 64-65
Page 64-65
Page 64-65
