# - Fast Moving Parts
* - Non Illustrated Parts 5 03/99
Publication number
FEF336BGWD, FEF336BGDD 5995319927
CAUTION: Use the part number on all orders, not the position number.
BODY
A=FEF336BG (FEF336BGWD)
B=FEF336BG (FEF336BGDD)
POS. NO PART NO DESCRIPTION
* 3203550 A B Plug-button
* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,
A B ind lght brkt,manifold pnl
* 316045000 A B Clip-wire,harness ,main top
* 5303051099 A B Nut,hex ,#10-32
1 316080804 A B Back-main, short,dipped ,black
3 316081036 - B Panel-bodyside, almond, RH
3 316081037 - B Panel-bodyside, almond, LH
3 316081034 A Panel-bodyside,white ,RH
3 316081035 A Panel-bodyside,white ,LH
5 316107300 A B Screw-leveling
6 316067902 A B Rack-oven
7 316007001 A B Hinge-oven door,(2)
8 3203540 A B Panel-oven bottom
9 316073800 A B Pan-broiler
10 3205234 A B Insert-broiler pan
14 316116400 A B Socket-light
15 5303013071 A B Light Bulb/Lamp
21 3014099 A B Spacer-bodyside,(8)
27 5303284616 A B Clip-thermo bulb
29 3051162 A B Glide-drawer,front
30 5303283574 A B Bracket-hinge,main top RH
30A 5303283575 A B Bracket-hinge,main top LH
41 3131570 A B Cover-hinge cutout
45 316066100 A B Shield-wire, s/t vent
57 316081101 A B Cover-access
58 3200847 A B Insulation,oven bottom
59 316073603 A B Tube-oven vent
59A 316023601 A B Tube-oven vent,upper
59B 316040100 A B Bracket-mounting,vent tube
62 # 5303935061 A B Terminal Block
63 5301145190 A B Plate-ground strap
66 # 5303051140 A B Element-broil
67 # 316075102 A B Element-bake,lower oven
68 316075300 A B Support-element, broil
71 316015805 A B Shield-rear wall
82 5303289913 A B Shield-insulation
87 316081200 A B Bracket-cable mtg
170 316107200 A B Anti-tip bracket
170* 316116000 A B Screw-Anti tip, 1.75" concrete
To Next Page
