FES388WG Pub li ca tion No.
5992325684
# = Func tional Part 3 07/99
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DE SCRIP TION
13A 316095500 A Switch-warmer in fi nite
14 5303051533 A Light/Lamp
18 5303300160 A End Cap black RH
18A 5303300161 A End Cap black LH
19 318005555 A Panel-control
20# 318012903 A Clock/Timer
21 318027803 A Trim-backguard
23 318015508 A Braket timer
24 # 316005602 A Switch-rocker
24B# 316086903 A Switch-rocker
36 318099202 A Knob con trol
36A 318017600 A Knob-warmer grey
42 318106903 A Trim-vent
46 5308006417 A Lens-light/lamp
54# 318120503 A Switch sur face unit
69 5303323134 A Screw mtg 8-32 X 3/16
102 318055601 A Bracket-mounting
* 3205110 A Clip, plate con nec tor
* 5303211311 A Screw, #8 X ½
* 08016432 A Screw, 8-18 X 3/8
* 08002868 A Screw, 10-24 X ½
* 5303323145 A Nut
* 218490900 A Cleaner stain less steel
A= FES388WG (FES388WGCF)
