Frigidaire FFHT1835VS User Manual

14
DOOR HANDLE INSTALLATION (SOME MODELS)
To attach the metal refrigerator handle
(Stainless steel, Black Stainless steel,
Stainless Steel EZCare):
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the 2 holes in
top of handle with the 2 holes in top
of the door. Do not tighten the set
screw yet.
2. Install the 2 screws into the top of
the handle.
3. Tighten the set screw on the rounded
part of the handle until the handle
is flush with the door; then tighten
another ½ turn.
Screw
Handle
Button
Plug
Set
Screw
Shoulder
Screw
Shoulder
Screw
Nameplate
Handle
Set Screw
Screw
Rounded Doors
To attach the metal freezer handle
(Stainless steel, Black Stainless steel,
Stainless Steel EZCare):
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the 2 holes in
bottom of handle with the 2 holes in
bottom of door. Do not tighten the
set screw yet.
2. Install the 2 screws into the bottom
of the handle.
3. Tighten the set screw on the
rounded part of the handle until the
handle is flush with the door; then
tighten another ½ turn.
Flat Doors

Frigidaire FFHT1835VS Specifications

General

Type	freestanding
Style	top freezer
Color	stainless steel
Total Capacity	18.3 cu. ft.
Refrigerator Capacity	13.4 cu. ft.
Freezer Capacity	yes; 4.9 cu. ft.
Humidity Controlled Crispers	2 clear
Defrost System	automatic; frost free
Cooling System	eventemp cooling
Number of Refrigerator Shelves	2
Number of Refrigerator Adjustable Shelves	2
Number of Freezer Shelves	1
Number of Freezer Door Bins	2
Temperature Zones	single
Wine Rack	no
Dispenser	no
Ice Maker	optional
Water Filter	no
Air Filter	no
Control Type	electronic
Smart Home	no
Remote Control	no
Wi-Fi	no
Current	3.0a; 15

Weight and Dimensions

Depth	30 3/8 inch; 90° open 57"; 30 3/8"
Height	66 3/8 inch
Width	30 inch
