Frigidaire FFHT1835VS User Manual

16
DOOR HANDLE INSTALLATION (SOME MODELS)
To reverse the door handles:
2. Remove
the name
plate on the
freezer door.
3. Remove the
shoulder
screw on
the opposite
side of the
freezer door
and install
the shoulder
screw where
the name
plate was
removed
using an adjustable wrench or
Phillips head screwdriver.
4. Install the
name plate
on the
opposite
side of the
freezer door.
CAUTION
Be sure the doors are set aside in a
secure position where they cannot fall
and cause personal injury.
The handles may be easier to reverse
while the doors are o.
1. Unscrew
and remove
the handles
5. Remove the
button plugs
from the
front and
top of the
refrigerator
door.
6. Remove the
shoulder
screw on
the left side,
and install
the shoulder
screw on
the opposite
side of the
door using an adjustable wrench or
Phillips head screwdriver.
7. Install the
button
plugs on the
opposite side
of the front
and top of the
refrigerator
door
8. Reverse and
attach the
freezer and
refrigerator
handles as
shown.

Frigidaire FFHT1835VS Specifications

General

Type	freestanding
Style	top freezer
Color	stainless steel
Total Capacity	18.3 cu. ft.
Refrigerator Capacity	13.4 cu. ft.
Freezer Capacity	yes; 4.9 cu. ft.
Humidity Controlled Crispers	2 clear
Defrost System	automatic; frost free
Cooling System	eventemp cooling
Number of Refrigerator Shelves	2
Number of Refrigerator Adjustable Shelves	2
Number of Freezer Shelves	1
Number of Freezer Door Bins	2
Temperature Zones	single
Wine Rack	no
Dispenser	no
Ice Maker	optional
Water Filter	no
Air Filter	no
Control Type	electronic
Smart Home	no
Remote Control	no
Wi-Fi	no
Current	3.0a; 15

Weight and Dimensions

Depth	30 3/8 inch; 90° open 57"; 30 3/8"
Height	66 3/8 inch
Width	30 inch
