Frigidaire FGGC3645QS - Before Setting Surface Controls; Locations of the Gas Surface Burners

6
BEFORE SETTING SURFACE CONTROLS
LOCATIONS OF THE GAS SURFACE
BURNERS
1
The SIMMER burner is best used for simmering
delicate sauces, etc.
2
The STANDARD sized burners are used for most
surface cooking needs.
3
The POWER burner is best used for bringing large
quantities of liquid rapidly up to temperature or
when preparing larger quantities of food.
Figure 1 - Model FFGC3010
Figure 3 - Model FGGC3047
Figure 4 - Model FFGC3610
Figure 5 - Model FGGC3645Figure 2 - Model FGGC3045
1
11
1
1
1
2
2
2
2
2
2
2 2
2
2
2
2
3
3
3
3
3
