Frigidaire FGMV205KB User Manual

27
CLEANING AND CARE
CHARCOAL FILTERS
Charcoal Filters, which are attached with Hood Louver,
are used for nonvented, recirculated installation. The filter
should be changed every 6 to 12 months depending on
use.
1. Disconnect power to the microwave oven at the circuit
breaker panel or by unplugging.
2. Remove three Hood Louver Screws as in Figure 1.
3. Push in the upper tabs and pull the louver away from
the unit.
4. Remove the charcoal filters from hood louver and replace
new charcoal filters by piercing tabs into the holes in
charcoal filters.
5. Carefully push the louver back into place and replace
the screws removed at step 2.
Figure 1
Oven Light Cover
Hood Louver
Upper Tab
Bottom Tab
Hood Louver
Screws
Figure 2
Charcoal Filters
Inside of Hood Louver
Tabs
MICROWAVE OVEN LIGHT
1. To replace light bulb, first disconnect power to the
microwave oven at the circuit breaker panel or by
unplugging.
2. Remove the louver per instructions under Charcoal Filter
2-3. Open oven light cover by carefully pulling up on the
front edge. See figure 1.
3. Remove the light bulb and replace with a new 20
watt light bulb. DO NOT USE BULB LARGER THAN 20
WATTS.
4. Close the Oven Light Cover by carefully pushing into
place. Push the louver back into place (engaging both
the bottom and top tabs) and change to hood Louver
Screws.
WORK/NIGHT LIGHT
1. To replace light bulbs, first disconnect power to the
microwave oven at the circuit breaker panel or by
unplugging.
2. To open Light Cover, remove the screw on the light cover.
(See Figure 3.)
3. Replace the light bulbs with new 20 watt light bulbs. DO
NOT USE BULBS LARGER THAN 20 WATTS.
4. Close the Light Cover and secure with screw removed
at step 2.
(Front of microwave oven)
(Rear of microwave oven)
Light Bulbs
Light Cover
Figure 3
Screw
BOTTOM VIEW
Disconnect the power cord before cleaning or
leave the door open to deactivate the oven during cleaning.
CAUTION
Light Cover may become very hot. Do not press glass
when light is on.
U&C 2.0 side control_UL [B320] [27 27U&C 2.0 side control_UL [B320] [27 27 2/3/12 4:54:35 PM2/3/12 4:54:35 PM

Frigidaire FGMV205KB Specifications

General

Style	Over-the-Range
Color	Black
Total Capacity	1.7 Cu. Ft.
Temperature Settings	-
Cooking Programms	Grill
Power Levels	9
Fan Speeds	2 Speed
Venting Type	Convertible
Special Features	Child Safety Lock
Accessories	Metal Rack
Max Power Consumption	1650 W
Microwave Power	1000 W
Grill Power	-
Convection Power	-
Voltage	120 V
Frequency	60 Hz
Current	15 A

Weight and Dimensions

Depth	16 3/4 in
Height	17 1/16 in
Width	29-15/16 in
Net Weight	69 Lbs
