Operating Instructions
Operating Instructions
(continued)
11
.devreser sthgir llA.cnI ,stcudorP emoH xulortcelE 9002
ADDITIONAL THINGS YOU SHOULD KNOW
Now that you have mastered the operating procedure, here are more features in your control that you should become familiar with.
The "Cool" circuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly.
This prevents overheating of the compressor and possible circuit breaker tripping. The fan will continue
to run during this time.
There is a 2-Second delay for the compressor shutting down when selecting FAN ONLY. This is to cover the possibility of having
to roll through to select another mode.
After a power outage, the unit will memorize the last setting and return the unit to the same setting once power is restored.
Fresh Air Vent Control (on some models)
The Fresh Air Vent allows the air conditioner to:
1. Recirculate inside air - Vent Closed (see Fig. 1)
2. Draw fresh air into the room - Fresh Air (see Fig. 2)
3. Exchange air from the room - Vent Open (see Fig. 3)
Figure 1 (VENT CLOSED)
Figure 2 (FRESH AIR)
Figure 3 (VENT OPEN)
(6-WAY)
Air Directional Louvers
Air directional louvers control air flow direction. Your air conditioner has the louver
type described below.
Slider Type
ADJUSTER TABLET
The louvers will allow you to direct the air flow Up or Down and Left or Right
throughout the room as needed. Drag the adjuster tablet until the desired
Left/Right direction is obtained. Pivot horizontal louvers until the desired
Up/Down direction is obtained.
The control will maintain the set temperature within 2 degrees Fahrenheit, between 60°F and 90°F degrees.
TO TURN UNIT OFF:
Note: After the unit is turned off, the light on the display
will gradually fade away in 3 seconds. The unit will always
return to “eco” mode and “auto” fan speed setting when it
is turned on again.
YOU WILL SEE:
DO THIS:
PRESS
ON/OFF BUTTON
