Frigidaire FRS095YC1 - Indoor Unit Installation

Indoor unit installation
Installation plates and dimensions
A
above 150mm from
the ceiling
Installation plate
indoor unit outline
above 120mm
from the wall
above 120mm
from the wall
Refrigerant pipe
hole (left) Ø 65
Refrigerant pipe
hole (right) Ø 65
B
45
90
40 40
Models < 12000 Btu's (A: 710, B: 250)
Models 12000 Btu's (A: 790, B: 265)
above 150mm
from the ceiling
Indoor unit outline
Installation plate
above 120mm
from the wall
above 120mm
from the wall
Refrigerant pipe
hole (left) Ø 65
Refrigerant pipe
hole (right) Ø 65
45
45
293
90
45
920
(A)
>
Models 12000 Btu's
1. This illustration is for explanation purposes only.
2. Copper lines must be insulated independently
7
8
5
4
2
3
1
Indoor unit
Outdoor
Unit
6
6
More
than 12cm
More than 12cm
Air filter
More than 200cm
More
than 60cm
More than 30cm
More than 60cm
More than 15cm
A
B
C
9
(B)
above 150mm
from the ceiling
Indoor unit outline
Installation plate
above 120mm
from the wall
above 120mm
from the wall
Refrigerant pipe
hole (left) Ø 65
Refrigerant pipe
hole (right) Ø 65
45
45
293
90
45
920
272
80
489
11 12
Attention
