36" GAS RANGE INSTALLATION INSTRUCTIONS
6
Air Shutter
Air Shutter
Waist-High Burner
Lower Oven Bottom
(removable)
Lower
Oven Burner
Bafe
(removable)
Figure 8
Oven Burner Tube
Orice Hood
Lock Screw
Air Shutter
3
2
1
Figure 9
8.5.3 Broil Burner Flame Adjustment
The approximate ame length of the burner is 1 inch
(distinct inner cone of blue ame). To determine if the
broil burner ame is proper, set the oven to broil. If
ame is yellow, increase air shutter opening size (see "2"
in Figure 9 ). If the entire ame is blue, reduce the air
shutter opening size. To adjust, loosen lock screw (see
"3" in Figure 9), reposition air shutter, and tighten lock
screw.
9. Make Sure Range Is Level
Check if the range is level by placing a level horizontally
on an oven rack. Check diagonally from front to back,
then level the range by either adjusting the leveling legs
or by placing shims under the corners of the range as
needed.
When All Hookups are Complete
Make sure all controls are left in the OFF position.
Make sure the ow of combustion and ventilation air to
the range is unobstructed.
Model and Serial Number Location
The serial plate is located on the oven front frame
behind the drawer.
When ordering parts for or making inquiries about
your range, always be sure to include the model and
serial numbers and a lot number or letter from the
serial plate on your range.
Your serial plate also tells you the rating of the
burners, the type of fuel and the pressure the range
was adjusted for when it left the factory.
Before You Call for Service
Read the Before You Call for Service Checklist and
operating instructions in your Use and Care Guide.
It may save you time and expense. The list includes
common occurrences that are not the result of
defective workmanship or materials in this appliance.
Refer to the warranty in your Use and Care Guide for
our service phone number and address. Please call or
write if you have inquiries about your product and/or
need to order parts.
systems require no adjustment. When the oven is set
to operate, current will ow to the igniter. It will "glow"
similar to a light bulb. When the igniter has reached
a temperature sufficient to ignite gas, the electrically
controlled oven valve will open and ame will appear at the
oven burner. There is a time lapse from 30 to 60 seconds
after thermostat is turned ON before the ame appears
at the oven burner. When the oven reaches the display
setting, the glowing igniter will go off. The burner ame
will go "out" in 20 to 30 seconds after igniter goes "OFF".
To maintain any given oven temperature, this cycle will
continue as long as the display is set to operate.
After removing all packing materials and literature from
the oven:
a) Set the oven to BAKE at 300°F. See Use & Care Guide
for operating instructions.
b) Within 60 seconds the oven burner should ignite.
Check for proper ame (see 8.5.2), and allow the
burner to cycle once (see cycle explanation above).
Reset controls to off.
c) If your model is equipped with a waist-high broiler
burner, set oven to broil. See Use & Care Guide for
operating instructions.
d) Within 60 seconds the broil burner should ignite. Check
for proper ame (see 8.5.3). Reset controls to off.
8.5.2 Oven Burner Flame Adjustment
The approximate oven burner ame length is 1 inch
(distinct inner cone of blue ame).
To determine if the oven burner ame is proper, remove
the oven bottom and burner bafe and set the oven to
bake at 300°F.
To remove the oven bottom, remove oven hold down
screws at rear of oven bottom. Pull up at rear, disengage
front of oven bottom from oven front frame, and pull the
oven bottom out of the oven. Remove burner bafe so
that burner ame can be observed.
If the ame is yellow, increase air shutter opening size
(see "2" in Figure 9). If the entire ame is blue, reduce
the air shutter opening size.
To adjust ame loosen lock screw (see "3" in Figure 9),
reposition air shutter, and tighten lock screw. Replace
oven bottom.
