# = Fast Moving Part 5 07/02
* = Non-Illustrated Part
GLDB653A Publication No.
5995375325
A = GLDB653A (GLDB653AS1)
B = GLDB653A (GLDB653AB1)
C = GLDB653A (GLDB653AQ1)
POS. NO PART NO DESCRIPTION
1 154365701 A B C Spring,door ,(2)
1A 154325201 A B C Linkage,door spring ,(2)
2 154093301 A B C Screw,arm assy ,(4)
3 154325304 A B C Arm Assy,LH
3A 154325303 A B C Arm Assy,RH
* 154400601 A B C Pin,arm assy
5 154079601 A B C Nut,arm assy ,(4)
7 154299002 A B C Door,inner assy
7A 154332701 A B C Grate,liner
9 154230101 A B C Dispenser,det/rinse aid ,includes #22
9* 154294701 A B C Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B C Screw,latch mtg ,(2)
12 # 154361201 A - - Latch assy,white
12 154361203 - B - Latch assy,black
12 # 154361204 - - C Latch assy,bisque
20 154359105 A - - Door,white
20 154359107 - B - Door,black
20 154359110 - - C Door,bisque
20* 5304428306 A B C Screw,door mtg. ,(2)
22 154388801 A B C Cap,Rinse aid
49 154297602 A B C Gasket,door ,bottom
50 154211401 A B C Support,door hinge
51 154320301 A B C Clamp,drip loop ,wire
* 154227808 A B C Thermostat,temp boost
* # 154227805 A B C Thermostat,temp assure
* 154200601 A B C Screw,#10-16 x 3/8
DOOR
