3
1. Unplug refrigerator from wall outlet.
2. Remove ice tray rack from freezer (some models).
3. Remove freezer shelf (some models) by pushing shelf
to left until right side of shelf is out of hole. Slowly lift
up and pull on shelf to remove.
4. Remove plugs from inside freezer compartment
with putty knife.
5. If refrigerator has exterior condenser (C), go to rear of
refrigerator and locate left condenser mounting bracket
screw(s). Remove and save screws. DO NOT remove
compressor sound baffle (A), if installed.Carefully bend
condenser out away from back of refrigerator.
If condenser is mounted inside compressor
compartment (D), remove screws securing
sound baffle to cabinet (B).
7. With needle nose pliers, remove foam from hole.
8. Push water inlet tube into small hole on back of
refrigerator. Rotate while inserting tube until flat
surface of inlet tube is tight against back of
refrigerator.
6. Peel off label covering ice maker hole.
