Frigidaire PRMC2285AF - Page 25

25
CONTROLS AND SETTINGS
Frigidaire Professional
Dispenser Controls
WATER Press WATER to select
water.
CRUSH Press CRUSH to select
crushed ice.
CUBE Press CUBE to select
cubed ice.
light Toggles dispenser light on
and o.
Clear Alerts
Door Open
If the freezer or fresh food doors have been
left open for five minutes or more, an alarm
will sound and the door ajar indicator will
illuminate on the display. Press CLEAR
ALERTS to reset any system alarms.
High Temp Alarm
High temp will illuminate next to clear alerts
button. Alarm is played every 60 seconds.
Press CLEAR ALERTS to acknowledge the
alarm The highest temp value will be dis-
played when the alarm is first acknowledged.
Power Outage
In the event of a power failure, the power
fail alert will be illuminated. Press CLEAR
ALERTS to acknowledge the alarm. Other
modes may be turned o until the alarm is
acknowledged. While a power failure alert
is displayed on the control panel, the unit
will continue normal operation. The high
temp alarm may also be illuminated until a
safe operating range temperature has been
reached.
Freezer Temp
If the freezer temperature reaches 26°F or
greater, the alarm will sound and the tem-
perature will flash and the dispenser control
will display HIGH TEMP DETECTED. You
can disable the alarm by pressing CLEAR
ALERTS but the HIGH TEMP DETECTED
indicator will illuminate until the temperature
goes below 26°F.
Fresh Food Temp
If the fresh food temperature reaches 55°F
or greater, the alarm will sound and the tem-
perature will flash and the dispenser control
will display HIGH TEMP DETECTED . You
can disable the alarm by pressing CLEAR
ALERTS but the HIGH TEMP DETECTED
indicator will illuminate until the temperature
goes below 55°F.
Flapper
When CUBE or CRUSH is selected, if the
flapper (or ice chute door) is being held
open by a jammed ice cube, an alarm will
sound and the current selection will blink on
the dispenser control. The alarm will reset
when the ice cube is removed.
