Product description
Air outlet
Air inlet
12
9
Outdoor unit
All the pictures in this manual are for
explanation purpose only. They may
be slightly different from the air
conditioner you purchased.
Air inlet
3
2
1
4
5
Air outlet
Indoor unit
7
6
Product description
Front panel
Air filter
Horizontal airflow grille
Vertical airflow grille
Temperature sensor
Panel
Remote control
Detection valve
Drain hose and refrigerant
connecting pipe
1
2
3
4
5
6
7
8
9
10
11
12
Attention
Infrared signal receiver
Connecting cable
(inside the indoor unit)
10
8
11
Refrigerant gas connector
(beneath front panel )
