FRIGOMAR ENG - CU50VFD-CU70VFD 20190108.doc81218 Page 6 of 24
3.2 WIRING DIAGRAMS
Fixing holes side accessibility
Warning! Never remove
PCB cover, adversely
warranty coverage will
decline
Terminal board
To enable
Fixing holes
accessibility from above
