Fromm P318 - Page 26

[ ] = Group * = Wearing parts
26
43083001.een.fm
[P32.1414] P31.0110 1 LEVER C24
P32.1415 P31.0110 1 HANDLE SHAFT C23
P32.1422 P32.1414 1 LEVER D23
[P32.2006] P31.0110 1 HANDLE LEVER B23
P32.2009 P31.1126 2 TURNING BUTTON C20
P32.2012 P31.0102 1 GUIDE C17
P32.2015 P32.0150 1 GEAR WHEEL A24
P32.2016 P31.0102 1 GEAR WHEEL B18
P32.2017 P31.0105 1 SWIVEL SHAFT C2
P32.2018 P32.0151 1 CONICAL GEAR WHEEL C22
P32.2020 P31.0102 1 COVER B7
P32.2023 P31.0102 1 FIXING PLATE A9
P32.2024 P31.0110 1 PRESSURE BUTTON B23
[P32.2026] P31.0102 1 LEVER B7
P32.2030 P31.0110 1 DISK B22
P32.2032 P31.0102 1 HOOK C17
P32.2034 P31.0109 1 SHAFT D15
P32.2036 P32.0156 1 GEAR WHEEL C14
P32.2064 P32.0172 1 COOLING PLATE B23
P32.2067 P31.0102 2 CENTERING SLEEVE C7
[P32.2078]
*
P32.0172 1 ELECTRIC MOTOR B23
[P32.2079] P31.0110 1 MOTOR HOUSING B24
[P32.2080] P31.0110 1 MOTOR HOUSING B22
P32.2121 P32.0172 1 DISK A23
43.0830.01 P318/13.0/0.35-0.80/PET P318.0001.01 27.10.09
Item-No. in group Pcs. Description Dimension Field
