TransCut 300
Operating Instructions
Spare Parts List
/ Battery Charging Systems / Welding Technology / Solar Electronics
Plasma cutting unit
EN
42,0426,0039,EN 002-11042012

Table of Contents

Questions and Answers

  • J
    Jocelyn BarnesAug 15, 2025
    Why is there excessive dross forming during cutting with my Fronius TransCut 300?
    • C
      Christopher HillAug 16, 2025
      Excessive dross formation during cutting can occur if the cutting speed is either too fast or too slow, so adjust the cutting speed accordingly. It could also be due to the cutting current being too low, so you may need to increase it. Ensure you've selected the correct operating mode. Also, check that the cutting torch is applied correctly, using a slight forward inclination.
  • R
    Ryan RobertsonAug 19, 2025
    What to do if my Fronius TransCut 300 Cutter has poor cutting performance?
    • C
      Chad YoungAug 19, 2025
      Poor cutting performance with your Fronius Cutter can be due to several factors. Ensure that the cutting current isn't too low and that the distance from the workpiece isn't too great; increase the current or reduce the distance. A poor earth connection can also cause this, so check the contact between the earth terminal and the workpiece. If you're using a mains lead extension, try a shorter one.
  • A
    April WardAug 22, 2025
    Why does the arc break during cutting with my Fronius Cutter?
    • M
      Matthew RuizAug 22, 2025
      If the arc breaks during cutting with your Fronius Cutter, it could be due to a poor earth connection; check the contact between the earth terminal and the workpiece. Excessively worn wearing parts can also cause this, so replace them if needed. Using a very long mains lead extension or insufficient generator output may also lead to this issue; try a shorter extension lead or a more powerful generator.
  • M
    matthewgonzalezAug 25, 2025
    How to fix incomplete arc penetration with my Fronius TransCut 300 Cutter?
    • M
      marissa71Aug 25, 2025
      Incomplete arc penetration with the Fronius Cutter can occur if the cutting speed is too fast or the distance from the workpiece is too great; reduce the cutting speed or decrease the distance. Worn wearing parts or a poor earth connection may also be the cause, so replace the parts or check the earth terminal connection.
  • R
    rodgerscraigAug 28, 2025
    What does it mean when the torch indicator is lit on my Fronius Cutter?
    • C
      Cristian MuellerAug 28, 2025
      If the torch indicator is lit on your Fronius Cutter, it might be due to the protective cap or wearing parts being fitted incorrectly on the cutting torch. Ensure they are fitted correctly. It could also indicate that the wearing parts are faulty or worn, so replace them if necessary.
  • D
    Daniel HayesAug 31, 2025
    Why is steam escaping from the torch of my Fronius TransCut 300?
    • T
      Tamara BradyAug 31, 2025
      If steam is escaping between the body of the torch and the protective cap of your Fronius Cutter, ensure the protective cap is tightened correctly on the cutting torch. Also, the cutting nozzle cone might be dirty or damaged; clean it or install a new cutting nozzle.
  • L
    Luis HallSep 2, 2025
    What to do if the error indicator lights up on my Fronius TransCut 300 Cutter?
    • S
      Sara NguyenSep 2, 2025
      If the error indicator lights up on your Fronius Cutter, switch the device off and on again. If the error continues after restarting, you should notify After-Sales Service immediately.
  • J
    Jacob PetersenSep 5, 2025
    What does it mean when the fill level indicator is flashing on my Fronius TransCut 300 Cutter?
    • E
      econleySep 5, 2025
      If the fill level indicator is flashing on your Fronius Cutter, it means there is no cutting medium in the tank. Fill the tank with cutting medium.
  • C
    Carolyn SalazarSep 8, 2025
    What does it mean when the excess temperature indicator is lit on my Fronius Cutter?
    • M
      myerskellySep 8, 2025
      If the excess temperature indicator is lit on your Fronius Cutter, the device is overheating. Leave the device switched on and wait until it has cooled down. The indicator will turn off automatically once the device is ready for operation again.
  • C
    Chase RochaSep 12, 2025
    What does it mean when the fill level indicator is lit on my Fronius TransCut 300 Cutter?
    • R
      rebecca17Sep 12, 2025
      If the fill level indicator is lit on your Fronius Cutter, it means most of the cutting medium in the tank has been used up. Keep a cartridge of cutting medium at the ready or refill the tank.

Summary

Comprehensive Safety Rules

Hazard Level Definitions

Defines DANGER, WARNING, CAUTION, NOTE, and Important symbols for risk communication.

General Safety Remarks

Operational Guidelines and Responsibilities

Intended Use and Limitations

Personal Safety and Protection

Operator Responsibilities

Protecting Yourself and Others

Lists risks of plasma cutting and essential protective clothing and measures.

Specific Dangers and Precautions

Toxic Gases and Vapours

Warns about harmful gases produced during cutting and ventilation requirements.

Flying Sparks and Fire Hazards

Warns about fire/explosion risks from sparks and precautions for flammable materials.

Electrical Hazards

Highlights the fatal risk of electric shock and necessary insulation precautions.

Electrical Safety and EMC Measures

Continued Electrical Safety Advice

Continues safety advice on cables, connections, and working on the device.

EMC;EMF and Hazardous Area Precautions

Specific Hazardous Area Precautions

Hazardous Areas and Cutting Medium Safety

Continued Hazardous Area Precautions

Cutting Medium Cartridge Safety

Installation and Operation Safety

Installation and Transport Safety

Covers device stability, fire/explosion risks, workplace cleanliness, and transport safety.

Normal Mode Operation Safety

Emphasizes operating only with functional protection devices and avoiding bypass.

Compliance and Maintenance Checks

Controls and Operation

Operational Warnings and Guidance

Warning about incorrect operation and referencing necessary documents for safe use.

Device Controls Explained

Connections and Indicators

Continued Control Details

Connection Ports Identification

Pre-Commissioning Checks and Setup

Commissioning General Warnings

Warning about incorrect operation and referencing necessary documents for safe commissioning.

Intended Use and Setup Regulations

Commissioning Procedure

Commissioning Safety Precautions

Warning about electric shock risk during installation and requirements for safe operation.

Filling the Cutting System Tank

Cutting Process Preparation

Cutting Safety and Preparation Steps

Safety warnings and steps for preparing the workpiece and connecting to mains.

Cutting Techniques

Igniting the Plasma Jet Safely

Safety precautions for igniting the plasma jet, avoiding steam and hot metal.

Straight Line Cutting Methods

Wearing Parts Replacement

Torch Wearing Parts Replacement

Troubleshooting Guide

Troubleshooting Safety Precautions

Safety warnings before opening the machine and precautions for PE conductor connections.

Diagnosing Performance Issues

Lists common faults like poor penetration or performance and their causes/remedies.

Troubleshooting Specific Issues

Dross, Steam, and Indicator Issues

Indicator Lights and Error Codes

Care and Maintenance Schedule

General Care and Start-up Checks

Technical Specifications

Fronius TransCut 300 Specifications

General IconGeneral
Input Voltage3 x 400 V
Output Current300 A
Cutting Current Range20 - 300 A
Protection classIP 23
Operating Voltage3 x 400 V AC
CoolingAir cooled
Duty cycle60 %
