Frontier FM1015 - FM1012, FM1015 & FM1017 Trailer Assembly

Parts 41
5WPMAN0183 (Rev. 7/9/2008)
FM1012, FM1015 & FM1017 TRAILER ASSEMBLY
REF PART QTY DESCRIPTION
1 – – – – – 1 Trailer frame
2 5WP1009501 1 Hitch, Category 1 (FM1012)
-or-
2 5WP1009502 1 Hitch, Category 2 (FM1015 &
FM1017
3 5WP1006689 2 Link, Hitch adjustment
4 5WP44639 2 Sleeve, .76 x 1.00 x 4.12
5 5WP40804 1 Lock, Rear deck
6 5WP40880 1 Lever, Rear deck lock release
7 5WP40879 2 Lock, Wing deck
8 5WP40938 1 Lever, Wing deck lock release
9 5WP19201 1 H-Frame, CV drive
10 5WP44641 2 Sleeve, HT .78 x 1.00 x .69
11 5WP31464 2 Sleeve, .38 x .63 x .34
12 5WP23790 1 Jack, Parking
13 5WP21957 3 Spring, Comp .58 x .08 x 2.4 40
14 5WP484 2 Sleeve, HT .63 x 1.00 x .44
15 5WP3502 1 Bearing, Ball
16 – – – – – 1 Housing, Bearing (Not Serviced)
17 5WP1251 1 Bearing holder w/bearing
(Includes ref. 15, 16, 77, 78)
18 5WP44637 1 Shield, Front drive
19 – – – – – 1 Drive, Yoke & shaft Non-tel 2400 x
26.4 (see page 56)
20 5WP19407 1 Chain, Safety 6400 lb
21 5WP62440 2 Bumper pad
22 5WP38264 1 Pin, Lynch chain & cotter asy
23 5WP40933 1 Gearbox, 4-Way splitter
– – 5WP58815 2 Seal, Thru shaft 4-way gearbox
– – 5WP58816 2 Seal, Wing shaft 4-way gearbox
– – 5WP58817 6 Bearing, Cup & cone 4-way box
– – 5WP1009083 1 Plug, Vent w/Washer
24 5WP62626 4 Sleeve, .76 x 1.00 x 1.00
25 5WP44636 1 Shield, Gearbox 4-way
26 5WP1001020 2 Asy, Whl hub & axle (See page 46)
27 5WP38298G 2 Wheel & tire, 20.5 x 8.00 x 10 Gray
– – 5WP38475G Wheel rim, 5-Bolt 8.00 x 10 gray
28 5WP44625 1 Drive, Cmpl CV 2480, 35.8 x 48.4
(See page 54) -or-
28 5WP1021100 1 Drive, Cmpl CV 35R 35.0 x 47.6 (See
page 55)
29 5WP1023225 1 Drive, Cmpl 40, 26.9 x 43.5
(See page 50)
30 5WP58984 2 Pin, Rear wing hinge
31 5WP40805 1 Frame, Rear wWing
32 5WP44638 2 Chain, 16 Link 1/4-proof
REF PART QTY DESCRIPTION
33 5WP3443 1 Hydraulic Hose holder
34 5WP62484 1 Socket, SMV emblem
50 * Screw, HHCS 5/8 NC x 7-1/2 GR5
51 * Screw, HHCS 5/8 NC x 7 GR5
52 * Screw, HHCS 3/4 NC x 2-1/4 GR5
53 * Screw, HHCS 5/8 NC x 2 GR5
54 * Screw, HHCS 5/8 NC x 5 GR5
55 * Screw, HHCS 1/2 NC x 5-1/4 GR5
56 * Screw, HHCS 3/8 NC x 1 GR5
57 * Screw, HHCS 3/8 NC x 1-1/4 GR5
58 * Screw, HHCS 3/8 NC x 3-1/2 GR5
59 * Screw, HHCS 1/2 NC x 1-1/4 GR5
60 * Screw, HHCS 1/2 NC x 3 GR5
61 * Screw, HHCS 1/2 NC x 2 GR5
62 * Nut, Lock 5/8 NC
63 * Nut, Lock 3/4 NC
64 5WP11900 Nut, Flanged lock 1/2 NC
66 5WP14350 Nut, Flanged lock 3/8 NC
67 * Nut, Lock 3/8 NC
68 5WP28873 Washer, Flat .75 x 1.50 x .25
69 5WP44640 Washer, Cup 1.04 x 2.25 x .17
70 5WP34467 Washer, Flat .63 x 2.00 x .38
71 5WP10635 Washer, Cup .63 x 1.75 x 14 Ga
72 * Washer, Flat 3/8 standard
73 * Washer, Flat 1/2 standard
74 5WP57811 8 Washer, Flat 1/2 extra thick hrd
75 * Washer, Lock 3/8
76 5WP1258 Bolt, Wheel 1/2 NF x 1-1/8
77 * Grease fitting, 1/4-28 90° Tapered
thread
78 5WP12128 Ring, Retaining .06 x 72 MM
79 * Pin, Spirol 3/8 x 1-1/2
80 * Grease fitting,1/4-28 Taper thread
81 * Pin, Safety 3/16
82 5WP62789 Screw, HHCS 1/2 NC x 2 FT GR5
83 * Screw, HHCS1/2 NC x 1-3/4 GR5
84 5WP14139 Nut, Flanged lock 5/16 NC
85 * Bolt, Carriage 5/16 NC x 1/2
86 5WP1004251 1 SMV Bracket
87 5WP24611 1 Sign (SMV) Slow moving vehicle
* Standard Hardware, Obtain Locally
