Frontier FM1017 - Page 39

Parts 39
5WPMAN0183 (Rev. 7/9/2008)
FM1012, FM1015 & FM1017 MAIN FRAME ASSEMBLY
REF PART QTY DESCRIPTION
1 – – – – – 1 Trailer assembly (See page 40)
2 – – – – – 1 Right wing assembly (See page 42)
3 – – – – – 1 Left wing assembly (See page 42)
4 – – – – – 1 Right deck assembly FM1012
(See page 44) -or-
4 – – – – – 1 Right deck assembly FM1015,
FM1017 (See page 43)
5 – – – – – 1 Left deck assembly FM1012
(See page 44) -or-
5 – – – – – 1 Left deck assembly FM1015,
FM1017 (See page 43)
6 – – – – – 1 Center deck assembly FM1012
(See page 43) -or-
6 – – – – – 1 Center deck assembly FM1015,
FM1017 (See page 43)
7 5WP1023226 2 Drive, Cmpl 40, 21.3 x 32.3 FM1012
(See page 50) -or-
7 5WP1023227 2 Drive, Cmpl 40, 25.6 x 40.9 FM1015
(See page 50) -or-
7 5WP1023228 2 Drive, Cmpl 40, 28.3 x 46.4 FM1017
(See page 50)
8 – – – – – 6 Rotating caster (See page 45)
9 – – – – – 2 Non-rotating caster (See page 45)
10 – – – – – 4 Height adjustment post
(See page 46)
11 5WP58956 6 Caster arm asy w/bearing
5WP31780 12 Bushing, Oilite 1.25 x 1.50 x 1.50
* 6 Grease fitting, 1/4 - 28 Tapered
thread
12 5WP58968 2 Caster arm asy, Non-rotating
13 5WP40947 1 Caster arm asy, FM1012 -or-
13 5WP40944 1 Caster arm asy, Right, FM1015 -or-
13 5WP40942 1 Caster arm asy, Right, FM1017
14 5WP40947 1 Caster arm asy, FM1012
14 5WP40945 1 Caster arm asy, Left, FM1015 -or-
14 5WP40943 1 Caster arm asy, Left, FM1017
REF PART QTY DESCRIPTION
15 5WP58993 1 Caster arm asy, Right, FM1012 -or-
15 5WP58974 1 Caster arm asy, Right, FM1015,
FM1017
16 5WP58994 1 Caster arm asy, Left, FM1012
-or-
16 5WP58978 1 Caster arm asy, Left, FM1015,
FM1017
17 5WP38001 4 Pin, Wing hinge
18 5WP1791 6 Sleeve, HT .63 x 1.00 x .56
19 5WP38296 1 Rope, .25 x 95.0
20 5WP38295 3 Rope clamp
21 5WP38257 3 S-Hook, .25 x 2.25
22 5WP38294 1 Rope, .25 x 46.0
32 5WP1631 2 Pin, Headless 1.00 x 3.63
33 5WP40908 1 Complete decal set
50 * Screw, HHCS 5/8 NC x 2-1/2 GR5
51 * Screw, HHCS 1/2 NC x 1-3/4 GR5
52 * Screw, HHCS 1/2 NC x 3-1/4 GR5
53 5WP11900 Nut, Flanged lock 1/2 NC
54 5WP19025 Nut, Flanged lock 5/8 NC
57 * Washer, Flat 1" standard
60 * Pin, Safety 3/16
61 5WP62789 Screw, HHCS 1/2 NC x 2 FT GR5
62 5WP1003828 1 Manual tube assembly
63 5WP37420 2 Clamp, Hose 3.06 - 4.00
64 5WP1024650 1 Clutch shield kit
(includes items 65 through 68)
65 5WP1002048 3 Clutch shield
66 * Screw, HHCS M8 x 1.25P x 20 mm
67 * Washer, 5/16 lock
68 * Washer, 5/16 flat
* Standard Hardware, Obtain Locally
