Frontier FM1017 - REAR & WING DECK DRIVES (COMER); FM1012 Wing Drive; FM1015 Wing Drive; FM1017 Wing Drive

50 Parts
5WPMAN0183 (Rev. 7/9/2008)
FM1012, FM1015 & FM1017 REAR & WING DECK DRIVES (COMER)
FM1012 Wing Drive FM1015 Wing Drive
REF PART QTY DESCRIPTION
A 5WP1023226 Drive, Cmpl 40, 21.3 x 32.3
1 5WP1026999 1 Complete collar yoke C12
2 5WP36990 1 U-Joint Repair Kit 50
3 5WP38478 1 U-Joint Repair Kit 2300
4 5WP1001300 1 Complete collar yoke C12 1-3/8 - 6
5 5WP1019442 1 Outer cone fix ring
6 5WP30922 6 Protection fixing screw
7 5WP1019444 1 Inner cone fix ring
8 5WP1026987 1 Complete shield
9 NSS 1 Outer half shaft
10 NSS 1 Inner half shaft
11 5WP1001340 2 Lock collar repair kit
12 5WP1001306 1 Inner tube yoke
13 5WP1001305 1 Flexible pin
14 5WP1026985 1 Outer yoke & tube
15 5WP1026986 1 Inner yoke & tube
REF PART QTY DESCRIPTION
A 5WP1023227 Drive, Cmpl 40, 25.6 x 40.9
1 5WP1026999 1 Complete collar yoke C12
2 5WP36990 1 U-Joint Repair Kit 50
3 5WP38478 1 U-Joint Repair Kit 2300
4 5WP1001300 1 Complete collar yoke C12 1-3/8 - 6
5 5WP1019442 1 Outer cone fix ring
6 5WP30922 6 Protection fixing screw
7 5WP1019444 1 Inner cone fix ring
8 5WP1026990 1 Complete shield
9 NSS 1 Outer half shaft
10 NSS 1 Inner half shaft
11 5WP1001340 2 Lock collar repair kit
12 5WP1001306 1 Inner tube yoke
13 5WP1001305 1 Flexible pin
14 5WP1026988 1 Outer yoke & tube
15 5WP1026989 1 Inner yoke & tube
FM1017 Wing Drive All Rear Wing Drives
REF PART QTY DESCRIPTION
A 5WP1023228 Drive, Cmpl 40, 28.3 x 46.4
1 5WP1026999 1 Complete collar yoke C12
2 5WP36990 1 U-Joint Repair Kit 50
3 5WP38478 1 U-Joint Repair Kit 2300
4 5WP1001300 1 Complete collar yoke C12 1-3/8 - 6
5 5WP1019442 1 Outer cone fix ring
6 5WP30922 6 Protection fixing screw
7 5WP1019444 1 Inner cone fix ring
8 5WP1026998 1 Complete shield
9 NSS 1 Outer half shaft
10 NSS 1 Inner half shaft
11 5WP1001340 2 Lock collar repair kit
12 5WP1001306 1 Inner tube yoke
13 5WP1001305 1 Flexible pin
14 5WP1026991 1 Outer yoke & tube
15 5WP1026992 1 Inner yoke & tube
REF PART QTY DESCRIPTION
A 5WP1023225 Drive, Cmpl 40, 26.9 x 43.5
1 5WP1001300 1 Complete collar yoke C12 1-3/8 - 6
2 5WP38478 1 U-Joint Repair Kit 2300
3 5WP38478 1 U-Joint Repair Kit 2300
4 5WP1001300 1 Complete collar yoke C12 1-3/8 - 6
5 5WP1019442 1 Outer cone fix ring
6 5WP30922 6 Protection fixing screw
7 5WP1019444 1 Inner cone fix ring
8 5WP1026984 1 Complete shield
9 5WP1026978 1 Outer half shaft
(includes outer half of item 8)
10 5WP1026979 1 Inner half shaft
(includes inner half of item 8)
11 5WP1001340 2 Lock collar repair kit
12 5WP1001306 1 Inner tube yoke
13 5WP1001305 1 Flexible pin
14 NSS 1 Outer yoke & tube
15 NSS 1 Inner yoke & tube
NSS Not Serviced Separately
