Parts 35
5WPMAN0511 (Rev. 7/18/2008)
PARTS INDEX
MAIN FRAME ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 - 37
GEARBOX ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
DRIVESHAFT ASSEMBLY (WALTERSCHEID TWO-LOBE) . . . . . . . . .39
DRIVESHAFT ASSEMBLY (COMER). . . . . . . . . . . . . . . . . . . . . . . . . . .40
BLADE & SPINDLE ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
REAR CHAIN SHIELDING ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . .42
FRONT ROLLER ASSEMBLY (OPTIONAL). . . . . . . . . . . . . . . . . . . . . .42
QUICK HITCH KIT (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Rear Discharge
Grooming Mowers:
GM1060
GM1072
GM1084
