Frontier GM1190R User Manual

Parts 33
WPMAN0142 (Rev. 9/1/2004)
GM1190R MAIN FRAME ASSEMBLY
(EXPLODED VIEW)
REF PART NO
NO
NO USED DESCRIPTION
1 -------------- 1 Deck (not sold separately)
2 WP20787 2 Shield, Belt
6 WP1003409 1 Gearbox, 1.69:1
8 WP19535 1 Gearbox Stand
9 WP19570 2 Idler, Flat 5.95 Dia
10 WP27925 1 Sheave, P1 2 TB 11.4 PD
11 WP18990 1 V-Belt 2W140
12 WP19587 1 Guide, Belt
13 WP1482 1 Bushing, P1 1-1/4 In Strt Bore
14 WP28928 1 Spring, Ext .19 x 1.30 x 8.2
15 WP19541 1 Idler Arm Assembly
17 WP13557 3 Bushing, P1 1-3/8 In Strt Bore
18 WP19575 3 Sheave, P1 2 TB 5.4 PD
19 WP3444 3 Cover, Access Hole
20 WP19589 2 Skid, Side w/Hardware (includes
items 37 & 39)
21 WP24520 3 Spindle, Assembly Complete (see
breakdown on page 37)
23 WP24650KT 1 Roller Kit, Front Complete-
Optional (see breakdown on
page 38)
24 WP20137 1 Complete Decal Set - English
25 WP50138 1 Safety Decal Set - French
27 WP24590KT 1 CCW Blade, 13" long - Standard
-or- -or-
27 WP28329KT 1 CCW Low suction blade, 13" long
- Optional
28 WP19571 2 Idler, Flat 5.95 Dia Less Bearing
29 WP6095 2 Bearing, Ball
30 WP51849 1 Shield, Counter Cone
HARDWARE
REF PART
NO
NO DESCRIPTION
33 * Pin, Cotter 3/16 x 1-1/2
35 * Bolt, Carriage 3/8 NC x 1 GR5
36 WP21636 Bolt, Plow Clipped Hd 3/8 NC x 1-1/4
37 * Washer, Lock 3/8
38 * Nut, Hex 3/8 NC
39 WP14350 Nut, Flanged Lock 3/8 NC
40 WP20786 Grease Fitting, 1/4-28 M x 1/8 F NPT
41 WP18960 Grease Fitting, 1/8 M PTF x 2.63
42 WP24445 Bolt, Eye 7/16 NC x 3-1/2
43 * Nut, Hex 7/16 NC
44 * Washer, Flat 7/16 Standard
45 WP25475 Screw, HHCS 1/2 NC x 1 GR5 FT
46 * Screw, HHCS 1/2 NC x 1-1/4 GR5
47 * Screw, HHCS 1/2 NC x 2 GR5
48 * Washer, Lock 1/2
49 * Washer, Flat 1/2 SAE
50 WP29553 Washer, Flat .50 x 1.63 x .25
51 WP11900 Nut, Flanged Lock 1/2 NC
52 WP19024 Screw, Flngd Hex Head 5/8 NC x
1-3/4
53 * Bolt, Carriage 5/8 NC x 3 GR5
54 * Screw, HHCS 5/8 NC x 4 GR5
55 WP19025 Nut, Flanged Lock 5/8 NC
56 * Nut, Lock 5/8 NC
57 WP22060 Seal, Felt .63 x 1.00 x .25
58 WP27211 Sleeve, .63 x .88 x 1.18
59 WP11036 Washer, Shim .75 x 1.50 x 18 Ga
60 WP24801 Screw, HHCS M8 x 1.25P x 20mm
61 * Washer, Lock 5/16
62 * Washer, Flat Standard 5/16
* Obtain Locally
