Frontier LS2004 - Page 34

5CS2004OM (rev 00 07/2020) 34
10' Folding Boom
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
11 03H1810 1/4” x 1-1/2” Carriage Bolt 18
12 5CS43192 Tee 3/8 Barb w/ Nut 1
13 5CS43406 Nozzle Body Single Hose 3/8” 2
14 5CS43411 Spray Tip Screen 4
15 5CS43405 Nozzle Body Dual Hose 3/8” 2
16 5CS43843 Air Induction Spray Tip 0.4 gpm 4
17 5CS43014 In-line Valve 3/8” 2
18 FH325451 1/4” x 3” Carriage Bolt 2
19 3/8” Hose 2
CTL 4”, MF
5CS43286
20 3/8” Hose 2
CTL 14.5”, MF
5CS43286
21 3/8” Hose 2
CTL 29”, MF
5CS43286
- 5CS43652
Hose Clamp Screw Type 3/8” -
1/2”
12 Not Illustrated
Parts Diagrams
