Frontier LS2006 - Page 32

5CS2006OM (rev 00 07/2020) 32
Parts Diagrams
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
1 5CS61500 3 Point A Frame 1
2 5CS43603 Channel Left 1
3 5CS43602 Channel Right 1
4 5CS43605 Front Brace 2
5 5CS43618 Support 1
6 03H1495 3/8” x 1-1/2” Carriage Bolt 3
7 03H1500 3/8” x 1” Carriage Bolt 11
8 E55662 3/8" Flange Nut 20
9 5CS43883 Rear Crossmember 1
10 03H1540 5/16” x 3/4” Carriage Bolt 12
11 A22698 5/16” Flange Nut 16
12 5CS43610 Tank Clamp 4
13 03H2131 3/8” x 3” Carriage Bolt 4
14 5CS43620 Control Mounting Post 1
15 5CS65054 3/4” Star Lock Washer 2
16 T11234 3/8” Nylock Nut 2
17 T406296 3/8” Flat Washer 1
18 N10217 1/4” Flange Nut 11
Qty 11 for 18ft Boom,
Qty 8 for 12.5 ft Boom
and 24 ft Boomless
19 5CS62008 1/4” Bent Pin 1
20 03H1701 1/4” x 3/4” Carriage Bolt 9
Qty 9 for 18ft Boom,
Qty 6 for 12.5 ft Boom
and 24 ft Boomless
21 5CS60072 3/8” U-Bolt 1
22 5CS43315 5/16” x 1-3/4” Square U-Bolt 2
23 5CS43398 Lynch Pin 3
24 5CS43399 Top Link Pin, Cat 1 1
25 5CS43950 Manual Canister 1
26 5CS43621 Triple Control Mount 1 18ft boom
27 5CS43619 Single Control Mount 1
For 12.5 ft Boom and
24ft Boomless
Frame
