5CS2006OM (rev 00 07/2020) 39Parts Diagrams
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
9 5CS43403 Spring 3/4” x 3-3/4” x .105 2
10 03H1506 5/16” x 3” Carriage Bolt 2
11 03H2209 5/16” x 1-3/4” Carriage Bolt 14
12 A22698 5/16” Flange Nut 26
13 5CS65090 5/16” x 1-3/4” Hex Bolt 4
14 5CS43401 Plastic End Cap 1” 6
15 5CS43420 Tee 1/2” Barb 1
16 5CS50120 1/2”x4” Clevis Pin 2
17 5CS50237 Bowtie Clip 1/2” 2
18 5CS43411 Spray Tip Screen 7
19 1/2” Hose 1 CTL 6”, MF 5CS43418
20 1/2” Hose 1
CTL 22.25”, MF
5CS43418
21 1/2” Hose 3
CTL 29”, MF
5CS43418
- 5CS43652
Hose Clamp Screw Type 3/8” -
1/2”
13 Not Illustrated
18' Folding Boom
