Frontier LS2006 - Page 43

5CS2006OM (rev 00 07/2020) 43Parts Diagrams
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
11 5CS65163 7/16” Center Lock Nut 1
12 03H1705 7/16” x 3” Carriage Bolt 1
13 14H849 7/16” Hex Nut 1
14 5CS43781 1/4” x 4” J-Bolt 1
15 5CS43725 Spacer 1
16 5CS43810 1/4” Plastic Knob 1
17 5CS65154 1/4” Washer 1
18 03H1540 5/16” x 3/4” Carriage Bolt 8
19 A22698 5/16” Flange Nut 9
20 N10217 1/4” Flange Nut 5
21 5CS43435 Sprayer Handgun 1
22 T58694 5/16” x 5/8” Flange Bolt 1
23 5CS43588 Elbow 1/2” Barb - 1/2” NPT F 1
24 5CS43803 Elbow 1/2” Barb - 1/2” NPT M 1
25 TCU38060 1/4”x 1-1/2” Bolt 1
26 5CS43793 Front Mounting Bracket 1
27 5CS43794 Rear Mounting Bracket 1
28 5CS43804 Crossmember 1
29 5CS43988
Rubber Strap 5/16” x 1-1/4” x
10”
1
30 5CS65016 1/4” x 3/4” Truss Head Bolt 1
31 1/2” Hose 1
CTL 36”, MF
5CS43418
32 1/2” Hose 1
CTL 1200”, MF
5CS43418
- 5CS43652
Hose Clamp Screw Type 3/8” -
1/2”
4 Not Illustrated
100 ft Hose Reel
