RT 1142 - 1149
CAUTION: FIRMLY block tiller on horizontal surface.
Installing mast braces (PHASE 1)
1) Install spacer (D), bolt (F) and nut (B) on mast braces (A and G).
Do not tighten bolts and nuts at this time.
Installing parking stand (PHASE 2, operation 1)
2) Put parking stand (O) and fasten bolts (N) and nuts (M).
Tighten lock nuts to the requested tightening torque.
Installing mast braces on tiller (PHASE 2, operation 2)
3) Install mast assembly on tiller frame and tighten (see below fi gure). Bolts (I) and nuts (L) to the the
requested tightening torque.
• Fine Pitch screws: M12 x 1.25
• Class: 8.8
• Bolts tightening torques: 91 Nm (67 lb-ft).
ASSEMBLY
Assembly - Page 28
