PRODUCT IDENTIFICATION AND SERIAL NUMBER PLATE
AN INDIVIDUAL PRODUCT IDENTIFICATION AND SERIAL NUMBER IS ASSIGNED TO EACH MACHINE. WHEN WRITING ABOUT OR FILLING
OUT WARRANTY CLAIMS, USE ALL THE CHARACTERS SHOWN ON THE PLATE.
EXAMPLE: TY0660E002281
TY- FACTORY DESIGNATION (JDM DIVISION)
0660- MODEL OR MACHINE DESIGNATION
0660 - 660 PTO TILLER
E- CONFIGURATION CODE
002281- SERIAL NUMBER
PRODUCT CONFIGURATION CODE
THE CONFIGURATION «ALPHA» CODE IDENTIFIES A VARIATION OF A PRODUCT. (EXAMPLE: A 116 LAWN FACTOR MAY BE MANUFACTU-
RED AS A HYDROSTATIC OR MANUAL UNIT, AND BE SHIPPED WITH A 970MM OR 70MM MOWER. FOUR VARIATIONS OF THE 116 LAWN
TRACTOR EXIST.)
IT ALSO IDENTIFIES DIFFERENT PRODUCTS WHICH HAVE THE SAME MODEL OR MACHINE DESIGNATION.
EXAMPLE: 216 TRACTOR AND 216 TILLER).
IF NO CONFIGURATION «ALPHA» CODE IS REQUIRED, SPACE IS FILLED IN WITH AN «X».
SERIAL NUMBER LISTING INFORMATION
SERIAL NUMBER INFORMATION IS LISTED TO SHOW ON WHICH MACHINES EACH PART CAN BE USED; FOR EXAMPLE:
- THE PART CAN BE USED ON ALL MACHINES.
00000 - THE PART CAN BE USED ON ALL MACHINES BEGINNING WITH THE SERIAL NUMBER LISTED.
- 000000 THE PART CAN BE USED ON ALL MACHINES UP TO AND INCLUDING THE SERIAL NUMBER LISTED.
00000 - 000000 THE PART CAN BE USED ON ALL MACHINES BETWEEN AND INCLUDING THE SERIAL NUMBERS LISTED.
WHEN XXXXXX’S ARE LISTED IN PLACE OF A SERIAL NUMBER, A SERIAL NUMBER CHANGE WAS MADE, BUT THE EXACT SERIAL NUM-
BER WAS NOT AVAILABLE WHEN THF CATALOG WAS PRODUCED.
BOX-ENCLOSED ILLUSTRATIONS
A KEY NUMBER, SHOWN IN THE PARTS LIST, IS ASSIGNED TO A BOX ENCLOSING ALL PARTS SOLD AS A SERVICE ASSEMBLY.
BOLT AND CAP SCREW STRENGTH IDENTIFICATION
BOLTS AND CAP SCREWS REQUIRED TO HAVE HIGH-STRENGTH QUALITIES EQUIVALENT TO SAE GRADE 8 ARE IDENTIFIED THROU-
GHOUT THIS CATALOG BY THE DESCRIPTION HS SAE 8 (10.9 FOR METRIC). ALL STANDARD BOLTS AND CAP SCREWS ARE SAE GRADE
5 (METRIC 8.8) OR LOWER.
WHOLE GOODS LISTINGS
WHOLE GOODS ARE LISTED IN BOLD FACE TYPE. REFER TO LAWN AND GROUNDS CARE SALES MANUAL FOR WHOLE GOODS ORDE-
RING INFORMATION. ORDER SEPARATELY. DO NOT INCLUDE ON REPLACEMENT PARTS ORDER.
DIRECTION ARROW
ARROWS ARE USED WITH ILLUSTRATIONS TO INDICATE THE FRONT OF THE UNIT. «RIGHT-HAND» AND «LEFT-HAND» SIDES ARE DETER-
MINED BY FACING IN THE DIRECTION OF MACHINE FORWARD TRAVEL.
TO THE CUSTOMER
THE PART NUMBERS IN THIS PARTS CATALOG WERE CORRECT AT THE TIME THIS CATALOG WAS PUBLISHED. IT IS OUR POLICY TO
CONSTANTLY IMPROVE OUR MACHINES; THEREFORE, PART NUMBERS MAY CHANGE WHEN ORDERING PARTS. VERIFY PART NUMBERS
THROUGH YOUR DEALER.
