Frontier RT 1149 - Page 43

RT 1142 - 1149 - 1157 - 1165 - 1265 (October-16)
N. COD. DESCRIPTION
ROTOR (CONTINUED)
A2
RT 1142 - 1149
5
5
5
5
5
5
5
5
SERIAL N°. REMARKS
XFRT11X142088-;XFRT11X142101- (A)
XFRT11X142088-;XFRT11X142101- (B)
XFRT11X142088- (C)
XFRT11X142101- (D)
XFRT11X142088-;XFRT11X142101- (E)
XFRT11X142088-;XFRT11X142101- (F)
XFRT11X142088-;XFRT11X142101- (G)
1 MHF01010244 SCR. M10X1,25X25 U5740 8.8ZN
2 MH19100210 GASKET
3 MHF02050403 SEEGER RING E.72X2,5 U7437 C70
4 MHF04010179 BEARING D35 D72 B17 6207 2RSC3
5 MH41100425 ROTOR BEARING SUPPORT S.T.
6 MH73100405 LEFT HEL.BLADE 60X6 L/W
7 MH73100404 RIGHT HEL.BLADE 60X6 L/W
8 MHF20110021 BOLT M12X1,25X35F.18 ZP SPEC
9 MHF01480123 WASHER M12 ZGP EXTRA P.
10 MHF01200073 NUT M12X1,25 U5587 6SZN
11 MH00567202 BOLT M12X1,25X35 + N.+ W.
12 MHF01220034 NUT M10X1,25 D980 8ZN
13 MH41100404 EXTERIOR DUST COVER
14 MH41110421 HOES SHAFT ASSEMBL L10
14 MH41112421 HOES SHAFT ASSEMBL L12
15 MH41100426 ROTOR BEARING SUPPORT L.E
16 MH41100424 SPACER D=41 D=35 L=2
17 MHF02050146 ELASTIC RING DE 35X 1,5 U7435
18 MHF01100048 GREASE NIPPLE M8X1,25 U7663A
19 MH41100423 SPACER D=20.5 D=35 L=18.5
(A) For -XFRT11X142087 and -XFRT11X142100 and below fi t MHF04010214
(B) For -XFRT11X142087 and -XFRT11X142100 and below fi t MH41100405
(C) For -XFRT11X142087 and -XFRT11X142100 and below fi t MH41110401
(D) For -XFRT11X142087 and -XFRT11X142100 and below fi t MH41112401
(E) For -XFRT11X142087 and -XFRT11X142100 and below fi t MH41100406
(F) For -XFRT11X142087 and -XFRT11X142100 and below fi t MH41100203
(G) For -XFRT11X142087 and -XFRT11X142100 and below fi t MHF02050112
