RT 1142 - 1149 - 1157 - 1165 - 1265 (October-16)
N. COD. DESCRIPTION
FRAME (CONTINUED)
C1/m
RT 1265
5
5
5
5
5
5
5
5
1XFRT12XTE0140231- (A)
1XFRT12XTE0140231- (B)
MCRT1260X500914-; MCRT1265X500964- (C)
1XFRT12XTE0140231- (D)
1XFRT12XTE0140231- (E)
SERIAL N°. REMARKS
1 MH69116700 CENTRAL FRAME 160C
2 MH69100933 EXTERNAL SIDE PANEL
3 MHF01010244 SCR. M10X1,25X25 U5740 8.8ZN
4 MHF01010283 SCR. M12X1,25X30 U5740 8.8ZN
5 MH63100957 EXTERNAL SKID
6 MHF01220047 NUT M12X1,25 D980 8ZN
7 MHF01010339 SCR. M16X1,5X40 U5740 8.8ZN
8 MHF02200529 SNAP PIN D.11 H58 ZN
9 MH58100930 ASSEMBLY CHAIN DMP L=476
10 MH63100954 STIRRUP
11 MH63100518 LOCKING BRACKET
12 MHF01220070 NUT M16X1,5 D980 8ZN
13 MH73100912 BUSHING D=28 (IN.D=22.5)
13 MH73100911 BUSH
14 MHF20100049 BOLT D22 L86 C43 ZN
15 MH63100907 CHAIN SIDE SKID
16 MHF01010057 SCR. M12X1,25X60 U5738 8.8ZN
17 MH01110532 ADJUSTER TOOTHED PLATE
18 MH66100778 LOCK PLATE L ZN
19 MH63116538 HINGE PIN LEVELLING PLATE
20 MH63100520 SKID ADJUSTER
21 MHF01010288 SCR. M12X1,25X35 U5740 8.8ZN
22 MH69100512 SUPPORT
23 MH69100511 LOCKING STIRRUP
24 MH69116520 LEVELLING BONNET
25 MH29100557 CHAIN
26 MHF01220059 NUT M14X1,5 D980 8ZN
27 MH71100530 CHAIN ATTACH.
28 MHF01010319 SCR. M14X1,5X45 U5740 8.8ZN
29 MH69100709 PLATE JD
30 MHF20100035 BOLT D19 L86 C43 ZN
31 MH69100707 LEFT 3° POINT HITCH SIDE PANEL
32 MH40200515 BUSH 3 POINT
33 MHF01010126 SCR. M16X1,5X110 U5738 8.8ZN
34 MHF20100101 BOLT D32 L128 C43 ZN
34 MHF20100035 BOLT D19 L86 C43 ZN
34 MHF20100063 PIN D25 L91 C43 ZN
35 MH69100708 RIGHT 3°POINT HITCH SIDE PANEL
36 MHF20100124 BOLT D32 L135 C40 ZN
37 MHF01480112 GROWER WASHER D.10
38 MHF01220034 NUT M10X1,25 D980 8ZN
(A) For -1XFRT12XTE0140230 and below fi t MH69116557
(B) For -1XFRT12XTE0140230 and below fi t MH69100546
(C) For -MCRT1260X500913 and -MCRT1265X500963 and below fi t MH63100936
(D) For -1XFRT12XTE0140230 and below fi t MH70100904
(E) For -1XFRT12XTE0140230 and below fi t MH70100903
