RT 1142 - 1149 - 1157 - 1165 - 1265 (October-16)
N. COD. DESCRIPTION
TRANSMISSION (CONTINUED)
C6
RT 1265
5
1 MHF01010244 SCR. M10X1,25X25 U5740 8.8ZN
2 MH19100210 GASKET
3 MHF01220034 NUT M10X1,25 D980 8ZN
4 MH19116203 LEFT SPACER 160
5 MHF01020440 SCR. M8X1,25X25 U5739 8.8ZN
6 MHF01480099 GROWER WASHER D.8
7 MHF01020449 SCR. M8X1,25X35 U5739 8.8ZN
8 MH66100114 BRACKET
9 MHF04050070 BEARING D35 D72 T24,25 32207
10 MH19116202 TRANSMISSION SHAFT 160
11 MH71400100 SLEED GEARBOX "A2" SPEC.
12 MH19100207 GASKET MM.0,5
12 MH19100208 GASKET MM.0,3
12 MH19100209 GASKET MM.0,1
13 MHF03010286 OIL SEAL 45X60X7
14 MHF04050018 BEARING D45 D85 T20,75 30209
15 MH19100113 BEVEL GEAR PAIR
16 MHF01480112 GROWER WASHER D.10
17 MH69100102 POSTERIOR COVER
18 MH19100114 GASKET MM.0,05
18 MH19100106 GASKET MM.0,3
18 MH19100108 GASKET MM.0,5
18 MH19100109 GASKET MM.0,1
19 MHF04050072 BEARING D40 D80 T24,75 32208
20 MHF04050014 BEARING D35 D72 T18,25 30207
21 MHF03150630 OIL OUTLET PLUG 1/2"
22 MH69100101 GEARBOX
23 MHF02010111 SELF LOCKING NUT M30X1,5
24 MHF03010080 OIL SEAL 35X47X7 D3760NBR AS
25 MH33100103 BREATHER PLUG
26 MH69116201 OUTER SPACER
27 MH74100126 PROTECTION SUPPORT
28 MHF01410064 WASHER M10 10,5X20X2 U6592 ZN
29 MHF01020403 SCR. M6X1X16 U5739 8.8ZN
30 MHF01410037 WASHER M6 6,4X12,5X1,6 U6592ZN
31 MH01110144 CARDAN PROTECTION
32 MH38100146 P.T.O. PROTECTION
33 MHF03100174 GASKET SET A2
