Fryette C-5084-T User Manual

PITTBULL FORTY- FIVE 1X12 COMBO MODEL C-5084-T
SUPER THIRTY COMBO MODEL C-3084-S
REVISED 05/09/05
FRONT PANEL FUNCTIONS, RIGHT TO LEFT
1. REVERB- Initial set-up: 8 O’clock
2. EFFECTS MIX/LEVEL
- Initial set-up: 5 O’clock (not provided on earlier models).
3. EFFECTS SEND
- Send level set by preamp volumes
4. EFFECTS LOOP LEVEL
- Sets overall level of loop (Out = 0dB, In = -10,dB)
5. EFFECTS SERIES/PARALLEL SWITCH
- Sets loop for series or parallel operation (not
provided on earlier models).
6. EFFECTS RETURN
- Overall level adjusted by Hi/Low switch, then feeds to power amp
7. FOOTSWITCH JACK
- 6Pin Din Connector
8. LINE OUT
jack- Power amp line out
9. SPEAKER OUTPUT
- Parallel wired
10. IMPEDENCE SELECT- 4,8,16 ohm
11.
CLASS A/CLASS AB SWITCH- Sets operation of power tube to Class A or Class AB mode.
Forty-Five models only. Not available on earlier models.
12.
MAINS FUSE- AC line fuse. 3A Slo-Blo (USA), 3.5A Slo-Blo (Japan), T1.6A Time Delay Fuse
(Europe).
13.
GROUND SWITCH- 4,8,16 ohm. US and Japan only. Normally set to “0” position unless fully
grounded outlet in not available. Set for minimum hum.
