Fryette C-5084-T User Manual

TUBE FUNCTION AND LOCATION CHART
Each 12AX7 has two sections/functions. Section A is shown first, Section B is second. Factory
recommended tubes are listed under each location. Numbering sequence is right to left looking at
back of amp starting with the row closest to front panel of amp.
V1 (shielded tube) Reverb return amplifier.
12AX7WB Russia Input Gain Stage 1 and signal splitter for both channels
V2 Tone Control Driver, Drive channel
12AX7 China Gain Stage 3 for Drive channel
V3 Gain Stage 2 for Clean channel
12AX7 China Gain Stage 2 for Drive channel
V4 Reverb Driver.
12AT7 Not interchangeable with 12AX7, EF86 or EL84!!!
1995-1999 uses EL84
2001-2004 uses EF86
V5 Phase Inverter
12AX7 China Power amp input stage
V6-9 Power Tubes
EL84 Russia
V10 Rectifier Tube Forty-Five models only.
5AR4
