Frymaster SDU 50 - Page 11

8
Item Part # Component
1 Pipe Assembly, Discharge
823-4600
Standard (includes Item 2) (use 823-4617 for BKSDU)
823-4598
For use with Item 4 (Hose Discharge) (includes Item 3)
2 813-0115 Nipple, ¾-inch x 3-inch Toe
3 813-0031 Bushing, ¾-inch x ½-inch
4 810-1845
Hose, 24-inch Discharge (Optional) (use 810-2797 for 48-inch hose)
5 813-0109 Nipple, ¾-inch x Close
6 810-0784
Pump (includes handle 810-0657, which may be ordered separately)
* 826-1053
Kit, Pump Repair (includes two vanes, one spring, one rod, one gasket.)
* 816-0401 Seal, Pump Shaft
7 813-0032 Bushing 1-inch x ¾-inch Hex
8 823-4581 Pipe Assembly, Suction
9 810-0777 Pin, Plunger
10 Handle Assembly
823-2038 SDU50 and BKSDU
823-2421 SDU90
11 809-0119 Screw, 10-32 x ½-inch Slotted Head
12 Cover and Hinge Assembly
823-1683SP
SDU50 and BKSDU (does not include gasket (Item 13))
823-2422SP
SDU90 (does not include gasket (Item 13))
13
Gasket, Cover (attach with 3M 1300L adhesive or equivalent)
816-0134 SDU50 and BKSDU
816-0264 SDU90
14 816-0133 Gasket, Cover Hinge
15 Screen, Crumb
824-0438 SDU50 and BKSDU
824-0615 SDU90
16 826-1376 Nut, 10-32 Keps Hex (Pkg. of 10)
17 816-0132
O-ring, Suction Pipe Assembly (2 required)
18 809-0200 Washer, Wheel ½” SAE
19 809-0193 Washer, ¼-inch Nylon Flat
20 809-0191 Lock Washer, ¼-inch
21 809-0047 Nut, ¼-20 S/S Cap
22 810-0742 Latch, Tank Cover
23 809-0359 Screw, #8 x ¼-inch
24 809-1001 Screw, ¼-20 x ½” Slotted Head
25 802-0227 Label, Fill Line
26 Tank and Axle Assembly
823-4580SP SDU50 and BKSDU
826-2103 SDU50 Retrofit Kit for SDU’s manufactured before Jan. 2004.
823-4583 SDU90 If replacing tank manufactured pre-Jan.2004, 823-4581 will also be needed.
27 823-1911
Housing, 120VAC Receptacle (BKSDU only) (use 823-5060 for 240VAC)
28 807-1219
Receptacle, 120V 3-wire (BKSDU only) (use 807-4108 for 240VAC)
29 809-0266
Screw, #10 x ½-inch Phillips Truss Head (use 809-0396 for 240VAC Receptacle)
30 810-0783 Cotter Pin, Wheel
31 809-0054
Nut, 10-32 Elastic Lock (BKSDU only)
32 814-0051
Bumper, Rubber (BKSDU only)
33 809-0122
Screw, 10-32 x ⅝-inch Slotted Round Head (BKSDU only)
34 810-1112 Wheel, 7-inch x 1½-inch
35 807-1577
Heater, 120V 50W 5” x 10” (BKSDU only)
* 807-1224
Cord, Power – 120VAC (BKSDU only)** (use 106-4697 for 240VAC)
36 823-1915
Shield Heater (BKSDU only)
37 809-0104
Screw, 8-32 x ½-inch Slotted Truss Head (BKSDU only)
38 809-0247
Nut, 8-32 Keps Hex (BKSDU only)
* 815-0661 Adhesive, 3M 1300L
* Not illustrated.
** CAUTION: Risk of fire and electric shock. Replace only with manufacturer’s cord set, part No. 8071224 for 120V.
