9
NOTE: The BKSDU pump
assembly is identical to the SDU
50/SDU 90 pump assembly except
for the addition of the pump cover
and insulation and the modified
discharge pipe assembly.
1
2
3
4
5
6
6
ITEM PART # COMPONENT
1 823-1847 Cover and Handle Assembly, BKSDU
2 900-4429 Box, BKSDU Pump
3 811-0861 Insulation, 3-inch X 50-foot Adhesive-Backed Foam
4 823-4617 Pipe Assembly, BKSDU Discharge
5 809-0477 Screw, #10 X ¼-inch Philips Truss Head
6 809-0266 Screw, #10 X ½-inch Philips Truss Head
