Typical EZGO Golf Car wiring with F & R switch using ITS Converter

B-

B+

M-

Solenoid

Key

Pre-charge resistor

or PTC

ITS

CONVERTER

1 2 3 4

Directional

Selector SW

MS2

MS4

MS3

ITS

MS2 is closed when directional selector sw is in FWD or REV

MS3 is activated by accelerator pedal

MS4 is closed by directional selector switch in REV only

WHT

BLK

RED

ORN

GRN

RED

BLK

Optional Plug

Connection to

Motor A2

Pre-charge or PTC
