FSN IPS4000 - Page 30

30
11/2022
Standard Input Signal Table
Resolution
Timing Information Signal Source
H-Freq (KHz) V-Freq (Hz) Clock (MHz) HDMI DP SDI (12G) CVBS RGB
640 x 480 31.47 59.94 25.173 •• •
640 x 480 37.86 72.82 31.503 •• •
640 x 480 37.50 74.99 31.496 •• •
640 x 480 43.27 85.01 36.001 ••
800 x 600 35.16 56.25 36.000 •• •
800 x 600 37.88 60.32 40.000 •• •
800 x 600 48.08 72.19 50.000 •• •
800 x 600 46.88 75.00 49.500 •• •
800 x 600 53.67 85.06 56.250 ••
1024 x 768 48.36 60.00 65.000 •• •
1024 x 768 56.48 70.07 75.000 •• •
1024 x 768 60.02 75.03 78.750 •• •
1024 x 768 68.68 85.00 94.500 ••
1152 x 864 67.50 75.00 108.000 •• •
1280 x 720 44.76 60.00 74.486 •• •
1280 x 720 56.63 75.30 96.036 •• •
1280 x 720 58.63 84.84 117.500 ••
1280 x 960 60.02 60.02 108.043 •• •
1280 x 960 85.99 85.05 148.582 ••
1280 x 1024 63.98 60.02 108.500 •• •
1280 x 1024 79.98 75.03 135.000 •• •
1280 x 1024 91.15 85.02 157.500 ••
1600 x 1200 74.01 60.00 162.000 ••
1680 x 1050 64.67 59.88 119.000 •• •
1920 x 1200 74.04 59.95 154.000 ••
720 x 480i 15.74 59.94 13.500 • •••
720 x 576i 15.63 50.00 13.500 • •••
1280 x 720p 22.50 30.00 74.250 ••• •
1280 x 720p 37.50 50.00 74.250 ••• •
1280 x 720p 44.96 59.94 74.176 ••• •
1280 x 720p 45.00 60.00 74.250 ••• •
1920 x 1080i@50 28.13 50.00 74.250 ••• •
1920 x 1080i@59.94 33.72 59.94 74.176 ••• •
1920 x 1080p@25 28.13 25.00 74.250 ••• •
1920 x 1080p@29 33.72 29.97 74.176 ••• •
1920 x 1080p@30 33.75 30.00 74.250 ••• •
